Glensound Express Box MKII - For Simple Commentary Situations

  • Dale #:

    GLEN-EXPRESSBOXMKII
  • Availability:

    Not in Stock - Reserve Yours
  • This item is not in stock, but we can usually ship it within 10-20 days after your order is placed. Your payment will be charged after completing checkout.

Description

The Express Box MKII was designed to provide a quick and easy solution when it is necessary to provide interfacing for two commentators, with simple facilities. This high quality commentary unit is ideal for those looking for cost effective solutions without paying for unwanted features; the Expr... Read More

Shipping Charges Apply

Have a Question?

Call Toll Free: 888-462-7828 Live Chat Email Us

Suggested Accessories

Description

The Express Box MKII was designed to provide a quick and easy solution when it is necessary to provide interfacing for two commentators, with simple facilities. This high quality commentary unit is ideal for those looking for cost effective solutions without paying for unwanted features; the Express Box MKII is worthy of investigation.

Features:

  • Two commentary positions
  • Four external monitor inputs
  • Sidetone (own voice) monitor circuit
  • Other commentator monitor circuit
  • Two common talkback circuits
  • Operation of talkback buttons configurable
  • Mic inputs with selectable 48v phantom power
  • 7 LED PPM meter
  • Easy to use and cost effective

Inputs
Two front panel mic inputs with selectable 48v phantom power.

Outputs/Talkback
Each mic input has its own individual output. There is also a mixed output of the two mic inputs. The two talkback circuits have individual outputs and are common for both commentators.

Monitoring
There are four inputs for external sources, one sidetone pot of their own voice and one other commentator pot for listening to the co-commentator. These are available independently to each commentator on individual pots, so each can adjust the inputs for their own preference of mix level. There are two 6.35mm headphone sockets – 1 for each commentator. A 7 segment LED PPM meter displays level.

More +

Product Specs

MICROPHONE INPUTS
Mic Gain (Dynamic)54dB
Mic Gain (Phantom Power)44dB (37dB via internal link)
Input Impedance1k2
Noise @ Channel Outputs>= -70dB (22Hz - 22kHz A weighted 300 Ohm termination)
Noise @ Mix Output>= -67dB (22Hz - 22kHz A weighted 300 Ohm termination)
Phantom Power48 Volts @ 9.7mA
COMPRESSOR/ LIMITER
TypeComplex multi-point curve
Input Level
Output Level
-54
0
-44
+5
-34
+8.5
-24
+10
-19
+12.5
Headroom35dB
OUTPUTS
TypeElectronically balanced, fully protected
Impedance< 50 Ohms
SIGNAL PATH (Input to Output)
Frequency ResponseFlat : 53Hz to 10.5kHz
Frequency Response<= -1dB : 40Hz to 15.2kHz
Frequency Response<= -3dB : 30Hz to 22kHz
Distortion-44dB input : 100Hz <=0.04% : 1kHz <= 0.01% : 10kHz <= 0.006%
HEADPHONES
Line input impedance> 47kOhms
Frequency Response from Inputs>= +/-2dB 50 Hz to 24kHz
Gain/ Loss RangeOff to + 10dB
Headphone Impedance35 - 1000 Ohms
POWER
Mains Input85 - 264 VAC
Power Consumption3 Watts
SIZE & WEIGHT
Dimensions220 x 250 x 98mm (W x D x H)
Weight1.46 Kg
