HME BS410 Base Station for DX410 Intercom Systems
Availability:
Special Order ItemThis item is not stocked and needs to be ordered from the manufacturer. Please contact our sales team for more information.
Description
The BS410 is the base station for the DX410 wireless system, supporting up to 15 registered BP410 beltpacks and/or WH410 all-in-one wireless headsets. The system operates in the 2.4GHz frequency band and features high quality 7kHz wideband audio. The BS410 allows the option for audio bridging by combining 2-wire and 4-wire audio together on A or B channels.
Features:
- Two-channels
- 7kHz wideband audio
- 2-wire and 4-wire bridging
- 2-wire auto-nulling
- Lost packet concealment
- Upgraded radio
- Supports up to 15 beltpacks and/or wireless headsets
The DX410 is a newly designed two-channel digital wireless system, operating in the 2.4GHz band, that delivers an overall better experience in performance, range and sound. The system features 7kHz wideband audio, 2-wire and 4-wire bridging, and 2-wire auto-nulling for fast integration with Clear-Com or TW wired partyline systems.
| Audio | Channels: 2 audio channels Capacity: Up to 15 BP410 and/or WH410 per base station Full-Duplex: Yes. Single-channel = 4 in simultaneous full-duplex. Dual-channel = 3 in simultaneous full-duplex. Radio Frequency Range: 2400 Ð 2483.5 MHz Audio Frequency: 200 Hz Ð 7kHz 4-wire I/O: RJ45, 600 Ohms balanced, level adjustable, simultaneous operation with 2-wire 2-wire I/O: XLR-3M, XLR-3F, externally-switchable RTS or Clear-Com, 200 Ohms, level adjustable, null adjustable to 50dB attenuation, typical Aux Input: XLR-3F with _” (6.35mm) combo jack, 600 Ohms balanced, level adjustable Aux Output: XLR-3M, 600 Ohms balanced, level adjustable Headset Connector: 4-pin mini-DIN, Electret microphone Headset Output: 200mW into 32 Ohms Antenna Type: External _-wave dipole (R-TNC connector), RX/TX horizontal/vertical diversity System Distortion: <2% Communication Security: 64-bit encryption, dual-slot diversity |
| Transmitter | Type: Frequency Hopping, Spread Spectrum (FHSS) Transmit Power: 100mW burst Modulation Type: Gaussian filtered FSK, TDMA Frequency Stability: 13 ppm Harmonics/Spurious: Exceeds FCC and ETSI specifications over temperature |
| Receiver | Type: Frequency Hopping, Spread Spectrum (FHSS) RF Sensitivity: <-90dBm w 10-3 BER Frequency Stability: 13 ppm Distortion: <2% |
| Power Requirements: | 100 Ð 240 VAC, 50 Ð 60 Hz or 12 Ð 14 VDC |
| Environmental: | Temperature: +32¡F - +122¡F (0¡C - +50¡C) |
| Dimensions | 1.75 x 19.0 x 17.13 in (44 x 483 x 435 mm) (HxWxD) |
| Weight | 9 lbs (4.1 kg) |
The BS410 is the base station for the DX410 wireless system, supporting up to 15 registered BP410 beltpacks and/or WH410 all-in-one wireless headsets. The system operates in the 2.4GHz frequency band and features high quality 7kHz wideband audio. The BS410 allows the option for audio bridging by combining 2-wire and 4-wire audio together on A or B channels.
Features:
- Two-channels
- 7kHz wideband audio
- 2-wire and 4-wire bridging
- 2-wire auto-nulling
- Lost packet concealment
- Upgraded radio
- Supports up to 15 beltpacks and/or wireless headsets
The DX410 is a newly designed two-channel digital wireless system, operating in the 2.4GHz band, that delivers an overall better experience in performance, range and sound. The system features 7kHz wideband audio, 2-wire and 4-wire bridging, and 2-wire auto-nulling for fast integration with Clear-Com or TW wired partyline systems.
| Audio | Channels: 2 audio channels Capacity: Up to 15 BP410 and/or WH410 per base station Full-Duplex: Yes. Single-channel = 4 in simultaneous full-duplex. Dual-channel = 3 in simultaneous full-duplex. Radio Frequency Range: 2400 Ð 2483.5 MHz Audio Frequency: 200 Hz Ð 7kHz 4-wire I/O: RJ45, 600 Ohms balanced, level adjustable, simultaneous operation with 2-wire 2-wire I/O: XLR-3M, XLR-3F, externally-switchable RTS or Clear-Com, 200 Ohms, level adjustable, null adjustable to 50dB attenuation, typical Aux Input: XLR-3F with _” (6.35mm) combo jack, 600 Ohms balanced, level adjustable Aux Output: XLR-3M, 600 Ohms balanced, level adjustable Headset Connector: 4-pin mini-DIN, Electret microphone Headset Output: 200mW into 32 Ohms Antenna Type: External _-wave dipole (R-TNC connector), RX/TX horizontal/vertical diversity System Distortion: <2% Communication Security: 64-bit encryption, dual-slot diversity |
| Transmitter | Type: Frequency Hopping, Spread Spectrum (FHSS) Transmit Power: 100mW burst Modulation Type: Gaussian filtered FSK, TDMA Frequency Stability: 13 ppm Harmonics/Spurious: Exceeds FCC and ETSI specifications over temperature |
| Receiver | Type: Frequency Hopping, Spread Spectrum (FHSS) RF Sensitivity: <-90dBm w 10-3 BER Frequency Stability: 13 ppm Distortion: <2% |
| Power Requirements: | 100 Ð 240 VAC, 50 Ð 60 Hz or 12 Ð 14 VDC |
| Environmental: | Temperature: +32¡F - +122¡F (0¡C - +50¡C) |
| Dimensions | 1.75 x 19.0 x 17.13 in (44 x 483 x 435 mm) (HxWxD) |
| Weight | 9 lbs (4.1 kg) |
