JBL AC26-WH - Ultra-Compact 2-Way Install Speaker (White)
Contact us
Availability:
Special Order ItemThis item is not stocked and needs to be ordered from the manufacturer. Please contact our sales team for more information.
Description
The AC26 is an ultra-compact full-range loudspeaker system designed to provide maximum bandwidth and SPL in a single system package and yet be visually unobtrusive. The enclosure design allows for installation very close to walls and ceilings making it an ideal choice for under balcony, column, or wall mounting. The high frequency device is a 1 exit compression driver integrated into a newly designed 90Îç x 90Îç PT (Progressive Transition) waveguide providing even coverage throughout the intended listening area. The combination exhibits smooth power response resulting in extremely natural voicing. The AC26 utilizes dual 6.5 Symmetrical Field Geometry (SFG) LF Transducers each with a copper-clad aluminum edge wound 2 voice coil and a copper-clad pole piece that improves performance by reducing voice coil inductance and distortion. In addition Filtered Array Technology (FAT) is utilized to independently control the dual woofers for magnitude and phase response resulting in smoother power response and constant coverage.
Features:- Ultra compact enclosure
- Dual 165 mm (6.5 in) LF transducers
- 90Îç x 90Îç Progressive Transition waveguide with a 25 mm (1 in) exit compression driver
- Dual Neutrik NL4 connectors plus screw terminals
- Multiple Attachment Points for Ultimate Flexibility
The rugged multi-ply hardwood enclosure is designed to work in the vertical plane as well as in the horizontal plane. Mounting points are provided for an optional Ubracket and for an OmniMount type bracket. The AC26 is also equipped with attachment points located on the bottom of the enclosure for a stand mount accessory. The rugged plywood enclosure features JBL's textured DuraFlex finish and is equipped with a heavy duty powder coated steel, foam-backed grille.
| System | |
| Frequency Range (-10 dB) | 55 Hz - 20 kHz |
| Frequency Response (+/-3 dB) | 70 Hz - 18 kHz |
| Horizontal Coverage | 90¡ |
| Vertical Coverage | 90¡ |
| Directivity Factor (Q) | 7 (avg. 500 Hz - 16 kHz) |
| Directivity Index (DI) | 8 dB (avg. 500 Hz - 16 kHz) |
| System Sensitivity1 | 92 dB SPL/1W/1m |
| Rated Maximum SPL (1m)2 | 117 dB |
| System Nominal Impedance | 8 Ohms |
| Long-Term System Power Rating3 | |
| Continuous/Program/Peak | 180 W / 360 W / 720 W |
| AES Standard Power Rating4 | 350 W |
| Crossover | 2.2 kHz |
| Transducers | |
| Low Frequency Driver | 2 x JBL 226J, 165 mm (6.5 in) SFG driver with 50 mm (2 in) edge wound voice coil |
| High Frequency Driver | 1 x 2414H 25 mm (1 in) exit compression driver, 25 mm (1 in) voice coil |
| High-Frequency Waveguide | PT-B99HF-1 |
| Physical | |
| Enclosure | 12 mm and 15 mm exterior grade multi-ply hardwood plywood |
| Suspension Attachment | 6 x M8 points, 1 top, 3 bottom, 2 rear. 4 x M6 rear for OmniMount 30.0 |
| Finish | Black DuraFlex finish. White (-WH) available upon request |
| Optional Weather Resistant Versions5 | WRC / WRX available upon request |
| Grille | Powder coated 16 gauge perforated steel, acoustically transparent foam backing (grille cloth backing on white units) |
| Input Connectors | Neutrik Speakon NL4 (2 wired in parallel), plus CE-compliant covered barrier strip terminals. Barrier terminals accept up to 5.2 sq mm (10 AGW) wire or max width 9 mm (.375 in) spade lugs. NL4Õs +1/-1 in parallel with barrier strip (+2/-2 loop through) |
| Dimensions (H x W x D) | 539.8 x 199.4 x 226.1 mm (21.3 x 7.8 x 8.9 in) |
| Weight | 11.0 kg (24.3 lb) |
| Optional Accessories | MTU-26 U-Bracket 365469-001, M8 x 38mm Tee Knob Thumbscrew Kit for use with BMB-200k or K&M 195/8 stand mount accessory |
