||Eight 50 mm
(2 in) Full-Range
|Frequency Range (-10 dB)
||120 Hz – 20 kHz
||Vertical 20° (1.5 kHz - 16 kHz, ±10°)
Horizontal 150° (ave, 1 kHz – 4 kHz, ±20°)
|Sensitivity (2.83V@ 1m)
||93 dB (speech mode, 2 kHz - 14 kHz)
89 dB (music mode, 300 Hz - 18 kHz)
(8 ohm setting)
|150W (600W peak), 2 hrs
100 W (400W peak), 100 hrs
||Speech mode: 115 dB cont ave (121 peak)
Music mode: 111 dB cont ave (117 peak)
|70V/100V Transformer Taps
||60W, 30W, 15W, (7.5W at 70V only), and 8Ω thru, via switch
||Fiberglass reinforced ABS cabinet, painted aluminum grille
||IP-55 rated, per IEC529, when installed with optional MTC-PC2 panel cover. UV, moisture and 200-hr ASTM G85 acid-air/salt-spray resistant.
||Black or White (-WH)
||Ten M6 insert points on back panel.
||Included swivel (pan) / tilt wall bracket provides continuously variable +/-80 degree left-right swivel aiming (at no up/down tilt -- see Bracket Guide for maximum swivel range at various up/down tilt angles), continuously adjustable ±15 degree tilt, as well as 5 degree fixed increment points within the range. Ten threaded mounting points located on back panel located on back panel conform to industry standard rectangular 108 x 51 mm (4.25 x 2.0 in) pattern for OmniMount® 30.0 and other compatible third-party brackets. Threaded mounting points can be utilized for suspension.
|Safety Agency Rating
||EN54-24:2008 certified (Certificate No. 0359-CPR-00238), when installed with MTC-PC2 terminal panel cover. In accordance with the requirements of IEC60849/EN60849.
|Dimensions (H x W x D)
||528 x 99 x 153 mm
(20.8 x 3.9 x 6.0 in)
||4.1 kg (9.0 lb)
||Swivel (pan) / tilt wall bracket
MTC-PC2 terminal panel cover
||MTC-CBT-FM1 flush-mount low-profile wall-mount bracket
MTC-CBT-SMB1 Stand-Mount Bracket for use with 35 mm speaker stand
