JBL Control 226C/T 6.5 inch Coaxial Ceiling Loudspeaker with HF Compression Driver
Availability:
Special Order ItemThis item is not stocked and needs to be ordered from the manufacturer. Please contact our sales team for more information.
Description
Priced individually, but sold in pairs.
The JBL Professional Control 226C/T is a premium in-ceiling professional loudspeaker designed for applications requiring superior quality sound in ceiling mount applications.
Features:
- Consistent 120 deg. broadband pattern control for exceptional coverage
- Coaxial design featuring:
Kevlar-reinforced 165 mm (6.5 in) wooferÊ
25 mm (1 in) compression driver - Extraordinary clarity for speech and vocals with extended frequency response for music
- 150 Watts Power Handling
- Advanced high-slope crossover network for constant coverage and smooth, natural midrange
- Integrated back can with clean, contemporary grille
| Frequency Range (-10 dB) | 47 Hz - 19 kHz |
| Power Capacity | 150 W on 8-ohm setting |
| Tap Settings | 68W, 34W, 17W (plus 8.5W at 70V) |
| Sensitivity | 90 dB 95 dB computed for competitive comparison |
| Coverage | 120 degrees |
| Low Frequency | 165 mm (6.5 in) woofer Kevlar reinforced cone |
| High Frequency | 25 mm (1 in) exit compression driver |
| Dimensions (H x Dia) | O 330 mm (13 in) round baffle x depth from back of baffle of 246 mm (9.7 in) |
| Net Weight (ea) | 9.1 kg (20.0 lb) |
| Shipping Weight (pair) | 23.9 kg (52.5 lb) |
Priced individually, but sold in pairs.
The JBL Professional Control 226C/T is a premium in-ceiling professional loudspeaker designed for applications requiring superior quality sound in ceiling mount applications.
Features:
- Consistent 120 deg. broadband pattern control for exceptional coverage
- Coaxial design featuring:
Kevlar-reinforced 165 mm (6.5 in) wooferÊ
25 mm (1 in) compression driver - Extraordinary clarity for speech and vocals with extended frequency response for music
- 150 Watts Power Handling
- Advanced high-slope crossover network for constant coverage and smooth, natural midrange
- Integrated back can with clean, contemporary grille
| Frequency Range (-10 dB) | 47 Hz - 19 kHz |
| Power Capacity | 150 W on 8-ohm setting |
| Tap Settings | 68W, 34W, 17W (plus 8.5W at 70V) |
| Sensitivity | 90 dB 95 dB computed for competitive comparison |
| Coverage | 120 degrees |
| Low Frequency | 165 mm (6.5 in) woofer Kevlar reinforced cone |
| High Frequency | 25 mm (1 in) exit compression driver |
| Dimensions (H x Dia) | O 330 mm (13 in) round baffle x depth from back of baffle of 246 mm (9.7 in) |
| Net Weight (ea) | 9.1 kg (20.0 lb) |
| Shipping Weight (pair) | 23.9 kg (52.5 lb) |
