Description
The JRX215 is a portable, fifteen-inch, two-way speaker system designed specifically for applications in live music, music playback, and reinforcement of speech. With the smooth, natural sounding mid-range of the system, the JRX215 does a great job projecting live vocals, solos and speech. The extended lows and great top-end make it at home for music playback in DJ applications or anywhere live sound reinforcement is needed. Features include the dual-angle, 36 mm pole-mount socket as well as Neutrik® Speakon® and 1/4" input connectors.
Features:
- JBL 15 in low frequency driver with a 64 mm (2.5 in) diameter edgewound ribbon voice coil which provides more cross-sectional wire area in the voice coil gap than round wire designs, for greater efficiency and power handling.
- JBL 2414H-C 25 mm (1 in ) polymer diaphragm compression driver improves high frequency performance as well as system reliability.
- The advanced network topology crossover design shapes the frequency response to deliver coherent summation in the crossover region.
- High-voltage capacitors and inductors with massive cores and heavy gauge wire enable the crossover network to handle high power without saturating.
- Progressive Transition™ high frequency waveguide provides superior coverage control, reduced distortion, and smoother frequency response.
- The rugged, acoustically superior enclosure is constructed from 19 mm (.75 in ) MDF (Medium Density Fiberboard) using advanced adhesives and mechanical fastener technology for extreme durability and improved low-frequency performance.
- SonicGuard™ protects the high frequency driver from excess power without interrupting the performance.
- Non-resonant, all-steel handles are used.
- Attractive 18-gauge perforated, steel grille protects components from damage.
- Dual-angle pole-mount socket allows the speakers to tilt 10° for more uniform audience coverage.
Power Rating | 250 W / 1000 W |
Frequency Range (-10 dB) | 38 Hz - 19 kHz |
Frequency Response (+/-3 dB) | 50 Hz - 16 kHz |
Sensitivity (@1m) | 98 dB SPL (1w/1m) |
Nominal Impedance | 8 Ohms |
Recommended Amplifier Power | 250 W to 500 W into 8 ohms |
Maximum SPL | 128 dB |
Nominal Dispersion | 90¼ x 50¼ |
Crossover Frequency | 1.6 kHz |
Dimensions (H x W x D) | 699 mm x 460 mm x 432 mm (27.5 in x 18.1 in x 17 in) |
Weight | 27.4 kg (60.5 lb) |
High Frequency Driver | JBL 2414H-C 25mm (1 in) polymer diaphragm compression driver mounted on Progressive Transitionª Waveguide |
Low Frequency Driver | JBL M115-8A |
Input Connectors | Neutrik¨ Speakon¨ NL-4 (x1); .25 in TS phone jack (x1); parallel |
The JRX215 is a portable, fifteen-inch, two-way speaker system designed specifically for applications in live music, music playback, and reinforcement of speech. With the smooth, natural sounding mid-range of the system, the JRX215 does a great job projecting live vocals, solos and speech. The extended lows and great top-end make it at home for music playback in DJ applications or anywhere live sound reinforcement is needed. Features include the dual-angle, 36 mm pole-mount socket as well as Neutrik® Speakon® and 1/4" input connectors.
Features:
- JBL 15 in low frequency driver with a 64 mm (2.5 in) diameter edgewound ribbon voice coil which provides more cross-sectional wire area in the voice coil gap than round wire designs, for greater efficiency and power handling.
- JBL 2414H-C 25 mm (1 in ) polymer diaphragm compression driver improves high frequency performance as well as system reliability.
- The advanced network topology crossover design shapes the frequency response to deliver coherent summation in the crossover region.
- High-voltage capacitors and inductors with massive cores and heavy gauge wire enable the crossover network to handle high power without saturating.
- Progressive Transition™ high frequency waveguide provides superior coverage control, reduced distortion, and smoother frequency response.
- The rugged, acoustically superior enclosure is constructed from 19 mm (.75 in ) MDF (Medium Density Fiberboard) using advanced adhesives and mechanical fastener technology for extreme durability and improved low-frequency performance.
- SonicGuard™ protects the high frequency driver from excess power without interrupting the performance.
- Non-resonant, all-steel handles are used.
- Attractive 18-gauge perforated, steel grille protects components from damage.
- Dual-angle pole-mount socket allows the speakers to tilt 10° for more uniform audience coverage.
Power Rating | 250 W / 1000 W |
Frequency Range (-10 dB) | 38 Hz - 19 kHz |
Frequency Response (+/-3 dB) | 50 Hz - 16 kHz |
Sensitivity (@1m) | 98 dB SPL (1w/1m) |
Nominal Impedance | 8 Ohms |
Recommended Amplifier Power | 250 W to 500 W into 8 ohms |
Maximum SPL | 128 dB |
Nominal Dispersion | 90¼ x 50¼ |
Crossover Frequency | 1.6 kHz |
Dimensions (H x W x D) | 699 mm x 460 mm x 432 mm (27.5 in x 18.1 in x 17 in) |
Weight | 27.4 kg (60.5 lb) |
High Frequency Driver | JBL 2414H-C 25mm (1 in) polymer diaphragm compression driver mounted on Progressive Transitionª Waveguide |
Low Frequency Driver | JBL M115-8A |
Input Connectors | Neutrik¨ Speakon¨ NL-4 (x1); .25 in TS phone jack (x1); parallel |
