KGear GA201 - 2x125W Mini Power Amplifier
Availability:
Special Order ItemThis item is not stocked and needs to be ordered from the manufacturer. Please contact our sales team for more information.
Description
This tiny and essential amplifier is able to deliver 2x125W RMS to a load as low as 2 Ohm, providing an extremely flexible and reliable solution to sound distribution in small sized environments.
Up to 6 amplifiers can be linked together to expand the total amount of speakers thanks to a 3,5mm jack connector.
Designed for permanent installations such as retail shops, restaurants, hotels, pubs, bars and residential, GA201 is perfect for driving KGEAR GF speakers and GS6 subwoofer.
The compact modular design allows to fit up to 6 GA201 elements (12 channels) into 1 rack unit with G-RACKMINI accessory.
| Input Channels | 2 |
| Output Channels | 2 |
| Max Output Power per Channel | 125 Watt (RMS EIAJ @ 2 ohm 26VDC) |
| Minimum Impedance | 4½ (2½ bgm use) |
| Operating Voltage | 12-24 VDC 4A |
| Power Supply Operating Voltage | 85-245 VAC (external power supply included) |
| AC Current | 1A Nominal |
| Width | 72mm (2,83in) |
| Height | 42mm (1,65in) |
| Depth | 131mm (5,16in) |
| Rack adapter | G-RACKMINI |
| AUDIO I/O | |
| Analog unbalanced I | 3,5mm Jack, stereo |
| Analog power O | 2x Phoenix connectors |
| Line O | 3,5mm Jack, stereo (Link Out) |
This tiny and essential amplifier is able to deliver 2x125W RMS to a load as low as 2 Ohm, providing an extremely flexible and reliable solution to sound distribution in small sized environments.
Up to 6 amplifiers can be linked together to expand the total amount of speakers thanks to a 3,5mm jack connector.
Designed for permanent installations such as retail shops, restaurants, hotels, pubs, bars and residential, GA201 is perfect for driving KGEAR GF speakers and GS6 subwoofer.
The compact modular design allows to fit up to 6 GA201 elements (12 channels) into 1 rack unit with G-RACKMINI accessory.
| Input Channels | 2 |
| Output Channels | 2 |
| Max Output Power per Channel | 125 Watt (RMS EIAJ @ 2 ohm 26VDC) |
| Minimum Impedance | 4½ (2½ bgm use) |
| Operating Voltage | 12-24 VDC 4A |
| Power Supply Operating Voltage | 85-245 VAC (external power supply included) |
| AC Current | 1A Nominal |
| Width | 72mm (2,83in) |
| Height | 42mm (1,65in) |
| Depth | 131mm (5,16in) |
| Rack adapter | G-RACKMINI |
| AUDIO I/O | |
| Analog unbalanced I | 3,5mm Jack, stereo |
| Analog power O | 2x Phoenix connectors |
| Line O | 3,5mm Jack, stereo (Link Out) |
