Description
GPXA is a top of the line high performance active system and comprises of 2x18" powered subwoofer combined with GH412, a 4x12" passive coaxial slim array with K-array™ SAT® (Slim Array Technology), PAT® (Pure Array Technology) and a stainless steel cabinet.
With its built-in 4x1500W RMS amplifier, this system can drive a GPX passive system in a stereo configuration. It features Powersoft™ DSP and power module, controlled via ethernet with Armonia™ control software.
Thanks to its extreme performance and the compact format of the array, this system works in a stack configuration, with the array on top of the subwoofer. It is also possible to fly GH412 with our G-FLY flybar accessory, or place it on the ground with our G-BASE accessory.
Perfect for high SPL outdoor/indoor applications in large venues both for rental and permanent installations for touring, auditoriums, stadia, clubs, theme parks.
Type | Powered Sub + Satellite system |
Transducers | SUB: 2x 18Ó woofer TOP: 4x 12Ó coaxial woofer with 1Ó comp. driver |
Frequency Response | 30 Hz - 20 kHz (-6dB) |
Max SPL | 140 dB |
Coverage | V. 30¡ | H. 90¡ |
Amp Module | 4-channel Class-D |
Output Power | 4x 1500 W @ 4 ½ |
Power Consumption | 500W Rated Load (1/8 Max Output Power) |
Operating Voltage | 100-240V AC, 50-60 Hz |
DSP features | Remote control and tuning Input and Output Delay Parametric input EQ Output parametric filters |
Connectors | Volume potentiometer RJ45 for remote control 2x Combo XLR Input 2x SpeakON Output 1x PowerCon True AC MAINS |
Controls | Volume potentiometer Preset selector Remote control through Powersoftª Armon’aPlus Software |
Dimensions (WxHxD) | 1035 x 1905 (min) x 600 mm (40,75 x 75 x 23,6 in) |
Weight | 116,6kg (257 lb) |
Material | Subwoofer: Birch Plywood Satellite: Stainless steel |
Color | Black |
GPXA is a top of the line high performance active system and comprises of 2x18" powered subwoofer combined with GH412, a 4x12" passive coaxial slim array with K-array™ SAT® (Slim Array Technology), PAT® (Pure Array Technology) and a stainless steel cabinet.
With its built-in 4x1500W RMS amplifier, this system can drive a GPX passive system in a stereo configuration. It features Powersoft™ DSP and power module, controlled via ethernet with Armonia™ control software.
Thanks to its extreme performance and the compact format of the array, this system works in a stack configuration, with the array on top of the subwoofer. It is also possible to fly GH412 with our G-FLY flybar accessory, or place it on the ground with our G-BASE accessory.
Perfect for high SPL outdoor/indoor applications in large venues both for rental and permanent installations for touring, auditoriums, stadia, clubs, theme parks.
Type | Powered Sub + Satellite system |
Transducers | SUB: 2x 18Ó woofer TOP: 4x 12Ó coaxial woofer with 1Ó comp. driver |
Frequency Response | 30 Hz - 20 kHz (-6dB) |
Max SPL | 140 dB |
Coverage | V. 30¡ | H. 90¡ |
Amp Module | 4-channel Class-D |
Output Power | 4x 1500 W @ 4 ½ |
Power Consumption | 500W Rated Load (1/8 Max Output Power) |
Operating Voltage | 100-240V AC, 50-60 Hz |
DSP features | Remote control and tuning Input and Output Delay Parametric input EQ Output parametric filters |
Connectors | Volume potentiometer RJ45 for remote control 2x Combo XLR Input 2x SpeakON Output 1x PowerCon True AC MAINS |
Controls | Volume potentiometer Preset selector Remote control through Powersoftª Armon’aPlus Software |
Dimensions (WxHxD) | 1035 x 1905 (min) x 600 mm (40,75 x 75 x 23,6 in) |
Weight | 116,6kg (257 lb) |
Material | Subwoofer: Birch Plywood Satellite: Stainless steel |
Color | Black |
