Kramer PT-580T Compact HDMI Over BaseT Transmitter

  • Dale #:

    KRAM-PT580T
  • Availability:

    Not in Stock - Reserve Yours
  • This item is not in stock and needs to be ordered from the manufacturer. Your payment will be charged after completing checkout. We will strive to ship as soon as possible, pending availability.

Description

PT−580T is a compact high−performance, long−reach HDBaseT transmitter for 4K60Hz (4:2:0) HDMI signal over twisted pair. PT−580T converts the input signal into the transmitted HDBaseT signal. It extends video signals to up to 40m (130ft) over CAT copper cables at up to 4K@60Hz (4:2:0) 24bpp video ... Read More

Free Shipping (Continental US)

Have a Question?

Call Toll Free: 888-462-7828 Live Chat Email Us

Suggested Accessories

Description

PT−580T is a compact high−performance, long−reach HDBaseT transmitter for 4K60Hz (4:2:0) HDMI signal over twisted pair. PT−580T converts the input signal into the transmitted HDBaseT signal. It extends video signals to up to 40m (130ft) over CAT copper cables at up to 4K@60Hz (4:2:0) 24bpp video resolution and provides even further reach for lower HD video resolutions.

Features:

  •  High Performance Standard Extender — Professional HDBaseT extender for providing long–reach signals over twisted–pair copper infrastructures. PT–580T is a standard extender that can be connected to any market–available HDBaseT–compliant extension product. For optimum extension reach and performance, use recommended Kramer cables.
  •  HDMI Signal Extension — HDMI 2.0 and HDCP 2.2 compliant. Supports deep color, x.v.Color™, lip sync, HDMI uncompressed audio channels, Dolby TrueHD, DTS–HD, 2K, 4K, and 3D. EDID and CEC signals are passed through from the source to the display.
  •  I–EDIDPro™ Kramer Intelligent EDID Processing™ — Intelligent EDID handling, processing and pass–through algorithm that ensures Plug and Play operation for HDMI source and display systems.
  •  Multi–channel Audio Extension — Up to 32 channels of digital stereo uncompressed signals for supporting studio–grade surround sound.
  •  Cost–effective Maintenance — Status LED indicator facilitates easy local maintenance and troubleshooting.
  •  Easy Installation — Compact Pico TOOLS™ fan–less enclosure for dropped–ceiling or discreet mounting, or side–by–side mounting of 4 units in a 1U rack space with the optional RK–4PT rack adapter.

More +

Product Specs

INPUT 1 HDMI on an HDMI connector
OUTPUT 1 HDBT on an RJ–45 female connector
EXTENSION LINE HDBaseT 1.0 compliant
Up to 40m (130ft) at 4K @60Hz (4:2:0)
Up to 70m (230ft) at full HD (1080p @60Hz 36bpp)
Note: When using Kramer HDBaseT cables
VIDEO Up to 10.2Gbps bandwidth (3.4Gbps per graphic channel)
Up to 4K UHD @60Hz (4:2:0) 24bpp resolution
HDMI 2.0 and HDCP 2.2 signal compliance
POWER SOURCE 5V DC, 2A
POWER CONSUMPTION 5V DC, 570mA
ENCLOSURE Pico Tools size, Aluminium type
COOLING Convection ventilation
OPERATING TEMPERATURE 0° to +40°C (32° to 104°F)
STORAGE TEMPERATURE –40° to +70°C (–40° to 158°F)
HUMIDITY 10% to 90%, RHL non–condensing
INCLUDED ACCESSORIES Power supply unit
PRODUCT DIMENSION 6.22cm x 5.18cm x 2.44cm (2.45" x 2.04" x 0.96" ) W, D, H
PRODUCT WEIGHT 0.1kg (0.2lbs) approx.
SHIPPING DIMENSION 15.70cm x 12.00cm x 8.70cm (6.18" x 4.72" x 3.43" ) W, D, H
SHIPPING WEIGHT 0.4kg (0.9lbs) approx.
