    Description

    Combining very high output capability with Martin Audio's signature sonic performance and consistent coverage, the LE200 is the ultimate, everyday professional monitor. Its Coaxial Differential Dispersion drive unit comprises a powerful 15" (380mm)/3" (75mm) voice coil LF driver and a 1.4" (35mm) exit HF compression driver with a 3" (75mm) pure titanium diaphragm.

    Features:

    • Compact, two-way stage monitor
    • Coaxial 'point-source' performance
    • Differential Dispersion™ technology for consistent coverage
    • Defined, near-rectangular coverage plane at head-height
    • Switchable active/passive operation
    • Low-profile plywood enclosure
    • M8 rigging inserts
    • Multiple connectors for flexible deployment

    Applications:

    • Stage monitor


    Utilizing Coaxial Differential Dispersion technology, the LE200's horizontal coverage varies from 100° directly over the monitor, narrowing to 60° further back. This maintains the sound level and balance independent of distance from the monitor and produces a consistent near-rectangular coverage plane at head-height.

    The LE200 enclosure is constructed from durable plywood, features integral ergonomic handles, and is finished with a hard-wearing, black textured paint. A strong, perforated steel grille with an acoustically transparent cloth backing provides protection for the Coaxial Differential Dispersion driver, while moulded feet prevent movement onstage and protect against scratches to the base of the monitor.

    Switchable between bi-amp and passive operation, the LE200 incorporates an internal 1.6kHz passive crossover and four NL4 connectors located to suit a variety of user requirements. Compact and easy to manoeuvre, its exceptional performance, high output and consistent coverage makes the LE200 the definitive, affordable professional monitor for a wide range of applications.

    TYPE Two-way, bi-amp/passive Coaxial Differential Dispersion
    FREQUENCY RESPONSE 68Hz-18kHz ± 3dB,
    -10dB @ 50Hz
    DRIVERS
    • LF: 15” (380mm)/3” (75mm) voice coil, long excursion, shared ferrite motor system with HF
    • HF: 1.4” (32mm) exit/3” (75mm) voice coil, titanium dome compression driver
    RATED POWER 400W AES, 1600W peak
    SENSITIVITY
    • LF: 100dB, HF: 103dB
    • Passive: 100dB
    MAXIMUM SPL 133dB peak
    NOMINAL IMPEDANCE
    • LF/FR: 8½
    • HF: 8½
    DISPERSION (-6DB) 100¡-60¡ horizontal, 60¡ vertical
    CROSSOVER 1.2kHz active/passive (switchable)
    ENCLOSURE Birch/poplar ply
    FINISH Black textured paint
    PROTECTIVE GRILLE Black perforated steel with scrim cloth backing
    BAFFLE ANGLE 30û
    CONNECTORS 4 x NL4 type
    PIN CONNECTIONS
    • LF/FR: 1+/-
    • HF: 2+/-
    FITTINGS
    • 2 x pocket handles
    • Protective rubber feet on base and sides
    • 4 x M8 inserts
    DIMENSIONS (W) 610mm x (H) 364mm x (D) 562mm
    (W) 24.0ins x (H) 14.3ins x (D) 22.1ins
    DIMENSIONS INCL FEET (W) 616mm x (H) 367mm x (D) 562mm
    (W) 24.2ins x (H) 14.4ins x (D) 22.1ins
    WEIGHT 26kg (57.3lbs)
