Neumann KH 310 A Active Three-Way Studio Monitor - Right


  • Dale #:

    NEUM-KH310R
  • Availability:

    In Stock
  • Available for immediate shipment or pick-up from our Jamaica, NY warehouse. In-store pick-up is available Monday through Friday 8:30 am to 5:30 pm.

Description

The KH 310 A is a three-way system that reflects Neumann’s philosophy of achieving the most accurate sound reproduction using state-of-the-art technology and techniques. It exceeds the demands for a higher level of audio performance brought on by the transition to HDTV and 5.1 multichannel audio,... Read More

Shipping Charges Apply

Have a Question?

Call Toll Free: 888-462-7828 Live Chat Email Us

Suggested Accessories

Description

The KH 310 A is a three-way system that reflects Neumann’s philosophy of achieving the most accurate sound reproduction using state-of-the-art technology and techniques. It exceeds the demands for a higher level of audio performance brought on by the transition to HDTV and 5.1 multichannel audio, providing exceptional directivity and detail.

The KH 310 A features a Mathematically Modeled Dispersion™ Waveguide (MMD™), flexible acoustical controls, various input options and an extensive range of mounting hardware. This allows the loudspeaker to be used in diverse acoustical conditions, with any source equipment and in a wide variety of physical locations. The KH 310 A represents the latest in acoustic and electronic simulation and measurement technologies to ensure the most accurate sound reproduction possible.

The KH 310 A is designed for use as a near-field monitor, as a front loudspeaker in mid-sized multi-channel systems, or as a rear loudspeaker in a larger multi-channel system. It can be used in project, music, broadcast centers, OB vans, and post production studios for tracking, mixing, and mastering.

Features:

  • Elliptical Mathematically Modeled Dispersion™ waveguide for smoother off-axis response
  • Midrange driver reproduces important midrange frequencies and reduces Doppler effect, which reduces intermodulation distortion
  • Low-distortion high-frequency reproduction
  • Wide horizontal dispersion offers freedom of movement across the mixing console
  • Narrow vertical dispersion reduces reflections off the mixing console
  • One-piece front panel with no discontinuities for reduced diffraction and smoother frequency response

More +

Product Specs

Acoustics
-3 dB Free Field Frequency Response34 Hz - 21 kHz, ± 3 dB
Pass Band Free Field Frequency Response36 Hz - 20 kHz, ± 2 dB
Self-Generated Noise (with Input Gain Set to 100 dB for 0 dBu)< 20 dB(A) at 10 cm
Total Harmonic Distortion < 0.5 % at 95 dB SPLat 1 m>85 Hz
Max. SPL in Full Space / Calc. in Half Space at 3% THD at 1m110.3 / 116.3 dB SPL (averaged between 100 Hz and 6 kHz)
Bass Capability: Max. SPL in Half Space at 3% THD at 1m104.5 dB SPL (averaged between 50 Hz and 100 Hz)
Max. Short Term SPL with IEC-Weighted Noise (IEC 60286-5) at 1m, in Typical Listening Conditions113 dB(C) SPL
Max. Short Term SPL with Music Material at 2.3 m, in Typical Listening Conditions (pair)100 dB(C) SPL (full range)
107 dB(C) SPL (with subwoofer)
Max. Long Term SPL with Pink Noise at 2.3 m, in Typical Listening Conditions (single/pair)93 / 99 dB(C) SPL (full range)
94 / 100 dB(C) SPL (with subwoofer)
Electronics
Bass / Midrange / Treble Class AB Amplifiers, Cont. (peak) Output Power150 W (210 W) / 70 W (90 W) / 70 W (90 W)
Controller DesignAnalog, active
Crossover Frequencies650 Hz / 2 kHz
Crossover Slope24 dB/oct, 4th order
Equalization - Bass0, 2.5, 5, 7.5 dB
Equalization - Low Mid0, 1.5, 3, 4.5 dB
Equalization - Treble+1, 0, 1, 2 dB
Protection CircuitryIndependent thermo limiters for woofer, midrange dome and tweeter. Woofer soft clip and excursion limiters
Infrasonic Filter - Frequency; Slope15 Hz; 6 dB/oct
InputXLR, analog electronically balanced
Impedance, Electrically Balanced>13k Ohms
Input Gain Control (Sensitivity)0 dBu to 15 dBu
Output Level Control94, 100, 108, 114 dB SPL
CMRR>56 dB @ 100 - 15 kHz
Max. Input Level+24 dBu
Displays and Indicators - Power OnNeumann logo "White"
Displays and Indicators - Limit / ClipNeumann logo "Red"
Mains Power Supply, Voltage; Frequency100-240 V~; 50/60 Hz
Power Consumption - Idle24 W
Power Consumption - Full Output300 W
Mechanics
Cabinet Surface Finish, ColourPainted wood and polyurethane, Anthracite (RAL 7021).
Aluminum electronics panel, Black.
Baffle CoverOptional removable metal grille
Operating Conditions+10° C to +40° C (+50° F to +104° F), <90% RH, non-condensing
Transport/Storage Condition25° C to +70° C ( 13° F to 158° F), <90% RH, non-condensing
DriversMagnetically shielded
Woofer210 mm (8 1/4)
Midrange75 mm (3)
Tweeter25 mm (1)
Mounting Points2 x M8 on side panels, depth from outside of cabinet 25 mm (1").
Rear panel screws for attaching LH 41 base plate.
Rear panel bracket.
Product Dimensions (Height x Width x Depth), mm (inches)253 x 383 x 292 mm (10 x 15 1/8 x 11 1/2)
Net Volume, Internal / External16.2 liters / 28.3 liters
Product Weight13.0 kg (28 lbs 11 oz)
Packed Dimensions (Height x Width x Depth), mm (inches)590 x 380 x 360 mm (23 1/4 x 15 x 14 1/8)
Packed Weight and Cube16.8 kg (37 lbs 1 oz), 0.081 m³
Delivery Includes1x KH 310 A
3x Main cables (European, UK and US version
4x Self-adhesive feet
1x Operating manual
1x Supplement Getting Started Quickly
