Pliant Technologies CHB-8F 8-Port Fiber Hub for CrewCom Intercom
Availability:
Special Order ItemThis item is not stocked and needs to be ordered from the manufacturer. Please contact our sales team for more information.
Description
The CrewCom Fiber Hub is an eight port, 1RU, half-rack Copper Hub, provides routing and expansion capabilities to a CrewNet infrastructure via eight RJ-45 and a single duplex LC Fiber port. Power is received over a CrewNet copper connection or via a 48VDC power supply.
Features:
- Eight CrewNet ports
- First port is shared, either duplex LC Single Mode Fiber or copper
- Front and rear panel status indicators
- Micro USB connection for firmware updates
- Dual powering options
» Network power (Power over CrewNet)
» External power (48VDC) (recommended) - Standard 1RU half-rack size, forward or rear-facing orientation (rack kit sold separately)
- Integrated Ping function, which uses all LEDs to physically identify a target device
| CrewNet Ports (8 total connections) | (7) duplex LC for Single Mode Fiber; (1) duplex LC for Single Mode Fiber or RJ-45 for copper |
| Maximum CrewNet Line Length | Fiber 10,000 m (32,800 ft.); Copper 100 m (330 ft.) |
| External Power In | 48VDC Power Supply |
| Power-over-CrewNet (PoC) In | Port 1 (RJ-45) |
| Dimensions (L x W x H) | 21.9 cm _ 4.4 cm _ 22 cm (8.62 in. _ 1.73 in. _ 8.68 in.) |
| Weight | 794 g (1.75 lbs) |
| Operating Environment | -20¡ to 50¡ C (-4¡ to 122¡ F); 10% to 90% Humidity. |
| Maximum Altitude | 2,000 m (6,562 ft.) |
| RoHS | Yes |
| Compliance Model Number | HB2521 |
The CrewCom Fiber Hub is an eight port, 1RU, half-rack Copper Hub, provides routing and expansion capabilities to a CrewNet infrastructure via eight RJ-45 and a single duplex LC Fiber port. Power is received over a CrewNet copper connection or via a 48VDC power supply.
Features:
- Eight CrewNet ports
- First port is shared, either duplex LC Single Mode Fiber or copper
- Front and rear panel status indicators
- Micro USB connection for firmware updates
- Dual powering options
» Network power (Power over CrewNet)
» External power (48VDC) (recommended) - Standard 1RU half-rack size, forward or rear-facing orientation (rack kit sold separately)
- Integrated Ping function, which uses all LEDs to physically identify a target device
| CrewNet Ports (8 total connections) | (7) duplex LC for Single Mode Fiber; (1) duplex LC for Single Mode Fiber or RJ-45 for copper |
| Maximum CrewNet Line Length | Fiber 10,000 m (32,800 ft.); Copper 100 m (330 ft.) |
| External Power In | 48VDC Power Supply |
| Power-over-CrewNet (PoC) In | Port 1 (RJ-45) |
| Dimensions (L x W x H) | 21.9 cm _ 4.4 cm _ 22 cm (8.62 in. _ 1.73 in. _ 8.68 in.) |
| Weight | 794 g (1.75 lbs) |
| Operating Environment | -20¡ to 50¡ C (-4¡ to 122¡ F); 10% to 90% Humidity. |
| Maximum Altitude | 2,000 m (6,562 ft.) |
| RoHS | Yes |
| Compliance Model Number | HB2521 |
