PreSonus HP60 6 Channel Headphone Mixing System

  • Dale #:

    PRES-HP60
  • Availability:

    Not in Stock - Reserve Yours
  • This item is not in stock and needs to be ordered from the manufacturer. Your payment will be charged after completing checkout. We will strive to ship as soon as possible, pending availability.

Description

The HP60 solves a host of common headphone-monitoring problems. Each of its six headphone amps puts out 150 mW; if you can't hear this headphone system, you're stone deaf. Two global input channels and a Mix control let you adjust the click for each musician. Individual inputs let you send each m... Read More

Free Shipping (Continental US)

Have a Question?

Call Toll Free: 888-462-7828 Live Chat Email Us

Suggested Accessories

Description

The HP60 solves a host of common headphone-monitoring problems. Each of its six headphone amps puts out 150 mW; if you can't hear this headphone system, you're stone deaf. Two global input channels and a Mix control let you adjust the click for each musician. Individual inputs let you send each musician a custom mix for "more me".

Features:

  • 6 screaming-loud (150 mW/channel) headphone amplifiers with level control
  • 2 stereo input channels (A and B) with Mix control and Mute switch
  • T alkback-microphone input with level control, Talk button, and footswitch jack
  • 6 stereo 1/4" external analog line inputs (1 per channel) for "more me" with level control and Mono switch
  • 6 stereo 1/4" line outputs (1 per channel); carries a copy of the channel mix
  • 1 balanced XLR input for external dynamic talkback microphone
  • 1U 19" rack-mountable, rugged steel chassis
  • Internal power supply with standard IEC connector

The Problem Solver
"Turn my headphones up!" "More me, I can't hear myself!" "Turn down that click!" It gets old. Change that tune with the HP60 headphone distribution system. The HP60 is more than just a half-dozen headphone amps, it's a field-tested solution to a host of common headphone-monitoring problems.

Let's start with "turn my headphones up." Each of the HP60's six headphone amps has its own level control and puts out 150 mW, which is loud enough to drive the alligators out of the Louisiana swamps. If they can't hear this headphone system, they're stone deaf. More likely they'll scream, "turn it down, you're killing me!" Problem solved.

Now let's solve "turn down that click." The HP60 features two sets of line-level, stereo inputs that are routed to all six headphones; a Mix control that sets their relative levels for each headphone output. So you can feed the main control-room mix to channel A and the click to channel B and use the Mix controls to individually raise or lower the click relative to the main mix for each musician. Problem solved.

As for "more me," in addition to the two pairs of main stereo inputs, you get an external stereo input pair with level control for each headphone channel. A Mono switch lets you sum the left and right inputs. Additionally, a mute switch is provided for each headphone output.

So you can send each person a feed of just their instrument or voice and can control the level separately for each. Problem solved.

Take Command
With the HP60, when you talk, everyone listens. Hit the Talk button and use the talkback-mic input and your favorite dynamic mic to tell 'em what to do. You can even use a footswitch to control the talkback hands-free. Each channel also has stereo line outputs that can send a copy of the line-level headphone-channel mix to additional headphone amplifiers or monitor systems. So if you have a large band and need more than six headphones, you can chain two or more HP60s.

So get the problem solver, the most flexible and advanced headphone-mixing system in its price class: the PreSonus HP60.

More +

Product Specs

Inputs
Inputs A and B Connector Type (2 ea.) ¼” TRS balanced
External Input Connector Type ¼” TRS stereo unbalanced
Input Impedance 10 k

Headphone Outputs
Connector Type ¼” TRS stereo unbalanced
Max Output Power 150 mW/Ch.
Frequency Response 20 Hz - 20 kHz, ±0.5 dB, 60 load
Headphone Impedance Working Range 32 - 600

Power
Internal Supply, Standard IEC Connector 115 or 230 VAC

Physical
Dimensions 1/3U rack-mount (with standard rack tray, not included)
Height 1.75” (44.45 mm)
Depth 5.5” (139.7 mm)
Width 19” (482.6 mm)
Weight 8.0 lbs. (3.63 kg)
