QSC KS112 12-Inch 2000-Watt Powered Subwoofer
Availability:
Special Order ItemThis item is not stocked and needs to be ordered from the manufacturer. Please contact our sales team for more information.
Description
The KS112 is the perfect choice for anyone needing high output low-frequency extension in a highly compact and portable package. Powered by a 2000 watt class D amplifier module, KS112 features a single 12-inch transducer in a 6th order bandpass birch cabinet with rugged, low-noise casters. Onboard DSP provides variable crossover and savable/recallable Scenes for commonly-used applications while Intrinsic Correction tuning and loudspeaker management maximizes performance and protects the subwoofer’s components. Two M20 threaded pole receptacles provide connection to a threaded speaker pole in either vertical or horizontal deployment (pole not included). An optional K-SLOC security cover prevents unauthorized tampering of controls. Global 6-year warranty with product registration.
Features:
- High Output in an ultra-compact form factor
- 2000 Watt class D ampli er module
- 12-inch, long-excursion driver; 6th order bandpass design
- Variable crossover and savable/recallable Scenes for commonly used applications
- Intrinsic Correction tuning and loudspeaker management
- Re ned, professional appearance looks great in any application
- Rugged painted wood enclosure for long life and lasting durability
- Deployment in either vertical or horizontal positions with dual M20 speaker pole ttings
- Optional KS-LOC security cover prevents unauthorized tampering of controls
- Complete EASE & CAD information available online
- 6-Year Warranty
| Configuration | 6th-Order Bandpass Subwoofer |
| LF Transducer | 12-inch (305 mm), Cone |
| Frequency Response (-6 dB) | 41 Hz - 108 Hz |
| Frequency Range (-10 dB) | 38 - 121 Hz |
| Maximum Rated SPL | 128 dB @ 1 m (peak) |
| Amplifier | Class D |
| Rated Power | 2000 W (peak) |
| Cooling | Low-noise, variable speed fan |
| Controls | Power On/Off Gain Control Rotary encoder 2 x selection buttons |
| Indicators | 2 x Power LED (front and rear) Input Signal LED Limiter active LED |
| Connectors | 2 x locking XLR/F 1Ú4Ó combo 2 x XLR/M (Loop-thru Output) 1 x locking IEC power connector |
| AC Power Input | Universal power supply 100 Ð 240 VAC, 50 Ð 60 Hz |
| AC Power Consumption | 100 VAC, 2.4 A / 120 VAC, 2.0 A / 240 VAC, 1.3 A |
| Enclosure Details | |
| Enclosure | 15 mm Birch Plywood |
| Color | Black (RAL 9011) |
| Grille | Internal woofer cover |
| Dimensions (HxWxD) | 24.5 x 15.5 x 24.25 inches 622 x 394 x 616 mm |
| Net Weight: (including casters) | 28.4 kg (62.6 lbs) |
| Shipping Weight | 34.5 kg (76 lbs) |
| Regulatory | CE, WEEE, UL, China RoHS, RoHS II, FCC Class B |
| Included Accessories | 4 x Low-Noise, Heavy Duty Casters |
| Optional Accessories | KS112 Cover, KS-LOC Lock-Out Cover SP-16X Extension Pole, SP-36 Extension Pole |
The KS112 is the perfect choice for anyone needing high output low-frequency extension in a highly compact and portable package. Powered by a 2000 watt class D amplifier module, KS112 features a single 12-inch transducer in a 6th order bandpass birch cabinet with rugged, low-noise casters. Onboard DSP provides variable crossover and savable/recallable Scenes for commonly-used applications while Intrinsic Correction tuning and loudspeaker management maximizes performance and protects the subwoofer’s components. Two M20 threaded pole receptacles provide connection to a threaded speaker pole in either vertical or horizontal deployment (pole not included). An optional K-SLOC security cover prevents unauthorized tampering of controls. Global 6-year warranty with product registration.
Features:
- High Output in an ultra-compact form factor
- 2000 Watt class D ampli er module
- 12-inch, long-excursion driver; 6th order bandpass design
- Variable crossover and savable/recallable Scenes for commonly used applications
- Intrinsic Correction tuning and loudspeaker management
- Re ned, professional appearance looks great in any application
- Rugged painted wood enclosure for long life and lasting durability
- Deployment in either vertical or horizontal positions with dual M20 speaker pole ttings
- Optional KS-LOC security cover prevents unauthorized tampering of controls
- Complete EASE & CAD information available online
- 6-Year Warranty
| Configuration | 6th-Order Bandpass Subwoofer |
| LF Transducer | 12-inch (305 mm), Cone |
| Frequency Response (-6 dB) | 41 Hz - 108 Hz |
| Frequency Range (-10 dB) | 38 - 121 Hz |
| Maximum Rated SPL | 128 dB @ 1 m (peak) |
| Amplifier | Class D |
| Rated Power | 2000 W (peak) |
| Cooling | Low-noise, variable speed fan |
| Controls | Power On/Off Gain Control Rotary encoder 2 x selection buttons |
| Indicators | 2 x Power LED (front and rear) Input Signal LED Limiter active LED |
| Connectors | 2 x locking XLR/F 1Ú4Ó combo 2 x XLR/M (Loop-thru Output) 1 x locking IEC power connector |
| AC Power Input | Universal power supply 100 Ð 240 VAC, 50 Ð 60 Hz |
| AC Power Consumption | 100 VAC, 2.4 A / 120 VAC, 2.0 A / 240 VAC, 1.3 A |
| Enclosure Details | |
| Enclosure | 15 mm Birch Plywood |
| Color | Black (RAL 9011) |
| Grille | Internal woofer cover |
| Dimensions (HxWxD) | 24.5 x 15.5 x 24.25 inches 622 x 394 x 616 mm |
| Net Weight: (including casters) | 28.4 kg (62.6 lbs) |
| Shipping Weight | 34.5 kg (76 lbs) |
| Regulatory | CE, WEEE, UL, China RoHS, RoHS II, FCC Class B |
| Included Accessories | 4 x Low-Noise, Heavy Duty Casters |
| Optional Accessories | KS112 Cover, KS-LOC Lock-Out Cover SP-16X Extension Pole, SP-36 Extension Pole |
