DALE SKU # RADI-BACKTRACK

Radial Engineering Backtrack - Stereo Backing Track Source Switcher

Sale price$459.99 Regular price$552.00
Save $92.01
  • Availability:

    Special Order Item
  • This item is not stocked and needs to be ordered from the manufacturer. Please contact our sales team for more information.


  • LET OUR TEAM OF EXPERTS ASSIST YOU

    Description

    The Backtrack™ is a compact stereo audio switcher, perfect for bands running redundant backing tracks on stage or switching between any stereo audio sources.

    Features:

    • Switch between two stereo backing track sources on stage
    • Easily connect playback devices with 1/4" and 3.5mm TRS jacks
    • Headphone output for silently cueing up tracks
    • Transformer isolated main outputs eliminate hum and buzz


    Protect against playback failure
    For any performance that incorporates backing tracks or other pre-recorded elements, reliability is crucial to ensuring a smooth performance. Unfortunately, smartphone batteries die, laptops freeze up, and Murphy's Law will always apply. The Backtrack creates a redundant system to ensure that you can instantly switch over to a backup device should any problems arise with your primary playback source. This can be accomplished easily with the push of a button on the Backtrack or via a remote JR-2 footswitch, giving you peace of mind and freeing you up to focus on your performance without worry.

    Switch backing track sources remotely
    Use the JR-2 footswitch to mute or switch between playback sources. Monitor on stage with a powered speaker while simultaneously sending signal to the house PA system.

    Use the headphone output to cue up tracks
    The headphone output can listen to either input without switching the feed to the PA, allowing you to cue the next track and monitor silently on headphones.

    Switch between redundant amp modeling systems
    Take the balanced or unbalanced line-level outputs of two stereo amp modeling devices into the Backtrack; it will automatically balance the signal at the XLR outputs to the PA. Should one amp simulator go down, use the JR-2 to easily switch to the backup unit.

    Audio circuit type: Passive Audio Circuit with Active Headphone Amplifier
    Number of channels: 2
    Frequency response: 20Hz - 20kHz (-0.5dB/+0.5dB)
    Dynamic range: >+130dBu
    Total harmonic distortion: 0.007% @ 0dBu, 1kHz
    Intermodulation Distortion: 0.02% @ 0dBu, 1kHz
    Common Mode Rejection Ratio: 34dBu @ 60Hz, 42dBu @ 3kHz
    Noise: -105dBu
    Maximum Input: >+25dBu
    Features
    Ground lift, Headphone
    Input Connectors: 1/4" TRS, 3.5mm, RCA
    Output Connectors: XLR, 1/4" TRS
    Extras: Headphone output
    General
    Construction: 14-gauge steel chassis
    Size (L x W x D): 4.6" x 5.9" x 1.9" (11.7 x 15 x 4.8cm)
    Weight: 2.2 lb (1kg)
    Shipping size (L x W x D): 11.7" x 4.75" x 2.5" (29.7 x 12 x 6.4cm)
    Shipping weight: 3.25 lb (1.5kg)
    Power: 15VDC 100mA
    Conditions: For use in dry locations only between 5¡C and 40¡C
    Warranty: Radial 3-year, transferable

    The Backtrack™ is a compact stereo audio switcher, perfect for bands running redundant backing tracks on stage or switching between any stereo audio sources.

    Features:

    • Switch between two stereo backing track sources on stage
    • Easily connect playback devices with 1/4" and 3.5mm TRS jacks
    • Headphone output for silently cueing up tracks
    • Transformer isolated main outputs eliminate hum and buzz


    Protect against playback failure
    For any performance that incorporates backing tracks or other pre-recorded elements, reliability is crucial to ensuring a smooth performance. Unfortunately, smartphone batteries die, laptops freeze up, and Murphy's Law will always apply. The Backtrack creates a redundant system to ensure that you can instantly switch over to a backup device should any problems arise with your primary playback source. This can be accomplished easily with the push of a button on the Backtrack or via a remote JR-2 footswitch, giving you peace of mind and freeing you up to focus on your performance without worry.

    Switch backing track sources remotely
    Use the JR-2 footswitch to mute or switch between playback sources. Monitor on stage with a powered speaker while simultaneously sending signal to the house PA system.

    Use the headphone output to cue up tracks
    The headphone output can listen to either input without switching the feed to the PA, allowing you to cue the next track and monitor silently on headphones.

    Switch between redundant amp modeling systems
    Take the balanced or unbalanced line-level outputs of two stereo amp modeling devices into the Backtrack; it will automatically balance the signal at the XLR outputs to the PA. Should one amp simulator go down, use the JR-2 to easily switch to the backup unit.

    Audio circuit type: Passive Audio Circuit with Active Headphone Amplifier
    Number of channels: 2
    Frequency response: 20Hz - 20kHz (-0.5dB/+0.5dB)
    Dynamic range: >+130dBu
    Total harmonic distortion: 0.007% @ 0dBu, 1kHz
    Intermodulation Distortion: 0.02% @ 0dBu, 1kHz
    Common Mode Rejection Ratio: 34dBu @ 60Hz, 42dBu @ 3kHz
    Noise: -105dBu
    Maximum Input: >+25dBu
    Features
    Ground lift, Headphone
    Input Connectors: 1/4" TRS, 3.5mm, RCA
    Output Connectors: XLR, 1/4" TRS
    Extras: Headphone output
    General
    Construction: 14-gauge steel chassis
    Size (L x W x D): 4.6" x 5.9" x 1.9" (11.7 x 15 x 4.8cm)
    Weight: 2.2 lb (1kg)
    Shipping size (L x W x D): 11.7" x 4.75" x 2.5" (29.7 x 12 x 6.4cm)
    Shipping weight: 3.25 lb (1.5kg)
    Power: 15VDC 100mA
    Conditions: For use in dry locations only between 5¡C and 40¡C
    Warranty: Radial 3-year, transferable
