DALE SKU # RADI-OX8R

Radial Engineering OX8-R 8 Channel Passive 3 Way Microphone Splitter

Sale price$1,099.99 Regular price$1,320.00
Save $220.01
  • Availability:

    Special Order Item
  • This item is not stocked and needs to be ordered from the manufacturer. Please contact our sales team for more information.


  • LET OUR TEAM OF EXPERTS ASSIST YOU

    Description

    The Radial OX8 is a high-performance 8-channel microphone splitter that lets you send a microphone signal to as many as three consoles at the same time. Each channel is configured with a balanced input, a direct out which also serves as a return path for 48V phantom power, a thru-put with ground lift switch and a transformer isolated output.

    The OX8 is particularly well suited for live recording by delivering a transformer isolated audio signal path to the recording system while providing direct feeds to the front of house and monitor consoles. Transformer isolation eliminates hum and buzz cause by ground loops for ultra quiet results.

    Features:

    • Balanced 8-channel mic splitter in single space 19 frame
    • Eliminates hum and buzz caused by ground loops
    • Available with either Radial or Jensen transformers
    • Ideally suited for live recording, PA and broadcast

    For maximum flexibility, several connector options are available. Inputs may be accessed via the front panel, using standard XLRs, or the rear panel, with a choice of either 25 pin D-subs (wired to the Tascam standard) or Euro screw-down terminal connectors (Note: Wire-end terminal blocks are sold separately). Outputs include D-subs and Euro connectors, which are also located on the rear panel. These make it easy to connect to popular multi-track recording systems while providing easy termination for permanent installations.

    Although primarily designed for mic signals, the OX8 is equipped with a -36dB pad to accommodate line level sources, making the OX8 highly adaptable for all types of signal splitting. Several connector options are available to enhance flexibility. Inputs may be accessed via the front panel using standard XLRs, or via the rear panel with a choice of either 25 pin D-subs wired to the ProTools standard or screw-down Phoenix/Euro terminals which are commonly used in permanent installations.

    Because the OX8 is 100% passive, it does not require any power whatsoever to make it work. You simply plug in and the transformers do all the work. The OX8 comes standard with Radial custom wound mic bridging transformers or may be special ordered with Jensen Transformers for the ultimate purist. Each channel is further advantaged with RF filters to ensure absolute quiet performance even in the most noise-prone environments.

    Audio circuit typePassive mic/line splitter, transformer based
    Number of channelsThree-way splitter (one in/three out)
    Frequency response20Hz ~ 18KHz (+0dB/-3dB)
    Dynamic range140dB
    Maximum input+26dBu @ 1kHz
    THD +noise0.005% @ 1kHz
    Phase deviation1¡ @ 100Hz; 5¡ @ 20Hz
    CMRR114dB @ 60Hz
    Input impedance150 Ohms, balanced
    Output impedance150 Ohms, balanced
    Features
    TransformerRadial RT-DBS, 1:1 ratio
    ShieldDual Faraday, mu-metal can
    Input pad-36dB (allows line-level sources)
    Ground liftDisconnects XLR pin-1 at direct-2 and isolated output
    XLR configurationAES standard (pin-2 hot)
    DB-25 configurationTascam analog audio standard
    General
    Construction14 gauge steel chassis / outer shell
    FinishBaked enamel
    Size(W x H x D) 17.5" x 6" x 1.75" (44.5 x15.25 x 1.75cm)
    Weight7.5 lb (3.4 kg)
    Shipping SizeW x H x D: 22" x 10" x 4.5" (55.9 x 25.4 x 11.4cm)
    Shipping Weight8lbs (3.63kg)
    PowerPassive, no power required
    WarrantyRadial 3-year, transferable
