Description
Rolls continues to produce convenient, affordable problem solving utility devices. The MX28 Mini-Mix VI is a convenient 3 channel line mixer featuring stereo paired (L/R) 1/4 Phone inputs on each input. All 3 channels feature Volume and Pan control. Stereo paired (L/R) main out and 2 headphone outputs via 1/4 phone connectors are also featured. The convenient, compact light weight design makes the MX28 perfect for road use.
Features:
- Stereo Paired Inputs
The MX28 features three, stereo paired 1/4 phone inputs. These inputs make the MX28 an ideal solution for mixing signals from keyboards or consumer audio devices such as cassette decks, CD players etc. - Dual Headphone Outputs
Dual Headphone outputs provide flexible monitoring for both engineer and talent. - Master and Headphone Level
Headphone monitor level control separate from adjusts headphone level without effecting main mix level. - Volume and Pan Control
There are individual volume and pan controls on each input channel. Pan control adjust left or right stereo placement of audio signal. - Stereo Outputs
Stereo paired 1/4 Phone inputs are featured for sending a stereo signal to recorders, additioinal mixers or P.A.
Input Connections | 3 - Stereo paired (L/R) 1/4 Phone unbalanced |
Output Connectors | 1 - Stereo paired (L/R) 1/4 Phone unbalanced |
Max Input/Output Gain | +27 dBV Input: 10K Output: 100 |
Signal-to-Noise Ratio | < .005% |
Phantom Power | not applicable |
AC Power Requirements | 12 VDC 15-mA adapter (center negative) |
Dimensions | 4.25 x 1.75 x 4.5 (107.95 x 44.45 x 114.3mm) (W x H x D) |
Weight | 1.2 lb (.49 Kg) |
Rolls continues to produce convenient, affordable problem solving utility devices. The MX28 Mini-Mix VI is a convenient 3 channel line mixer featuring stereo paired (L/R) 1/4 Phone inputs on each input. All 3 channels feature Volume and Pan control. Stereo paired (L/R) main out and 2 headphone outputs via 1/4 phone connectors are also featured. The convenient, compact light weight design makes the MX28 perfect for road use.
Features:
- Stereo Paired Inputs
The MX28 features three, stereo paired 1/4 phone inputs. These inputs make the MX28 an ideal solution for mixing signals from keyboards or consumer audio devices such as cassette decks, CD players etc. - Dual Headphone Outputs
Dual Headphone outputs provide flexible monitoring for both engineer and talent. - Master and Headphone Level
Headphone monitor level control separate from adjusts headphone level without effecting main mix level. - Volume and Pan Control
There are individual volume and pan controls on each input channel. Pan control adjust left or right stereo placement of audio signal. - Stereo Outputs
Stereo paired 1/4 Phone inputs are featured for sending a stereo signal to recorders, additioinal mixers or P.A.
Input Connections | 3 - Stereo paired (L/R) 1/4 Phone unbalanced |
Output Connectors | 1 - Stereo paired (L/R) 1/4 Phone unbalanced |
Max Input/Output Gain | +27 dBV Input: 10K Output: 100 |
Signal-to-Noise Ratio | < .005% |
Phantom Power | not applicable |
AC Power Requirements | 12 VDC 15-mA adapter (center negative) |
Dimensions | 4.25 x 1.75 x 4.5 (107.95 x 44.45 x 114.3mm) (W x H x D) |
Weight | 1.2 lb (.49 Kg) |
