Description
The CS-3e stands out among shotgun microphones because it maintains directivity over an extremely wide frequency range, especially in the low frequencies. Because of its unique design, the CS-3e is an excellent choice for use in difficult applications, such as close-to-ceiling positions or locations near a noisy camera. Even in such challenging situations, the excellent side and rear rejection of the CS-3e helps to capture only the targeted dialogue without ambient reverberation problems. The CS-3e delivers sharp directional sound even in the lower frequencies. Sanken's original design results in a low proximity effect which facilitates working in a scene close-up and wide, while producing little change in sound character.
Features
- Location and studio shotgun featuring exceptional off-axis rejection
- Unique design combination of line mic array and second pressure gradient method
- Very sharp pinpoint directivity
- Provides rich human voice characteristics
Directivity | Super Cardioid / lobar |
Transducer | DC biased condenser |
Frequency range | 50Hz - 20kHz |
Sensitivity (nominal at 1kHz) | 50mV/Pa (-26dB,0dB=1V/Pa) |
Equivalent noise level (A-weighted) | 15dB-A |
Max SPL (1% THD) | 120dB SPL |
Output impedance at 1KHz | 120 ohms |
Powering | +48±4V phantom |
Current consumption | less than 3mA |
Weight | 120g |
Dimensions | 270mm X 19mm (diameter) |
Surface finish | matte black |
Connector | XLR-3M |
The CS-3e stands out among shotgun microphones because it maintains directivity over an extremely wide frequency range, especially in the low frequencies. Because of its unique design, the CS-3e is an excellent choice for use in difficult applications, such as close-to-ceiling positions or locations near a noisy camera. Even in such challenging situations, the excellent side and rear rejection of the CS-3e helps to capture only the targeted dialogue without ambient reverberation problems. The CS-3e delivers sharp directional sound even in the lower frequencies. Sanken's original design results in a low proximity effect which facilitates working in a scene close-up and wide, while producing little change in sound character.
Features
- Location and studio shotgun featuring exceptional off-axis rejection
- Unique design combination of line mic array and second pressure gradient method
- Very sharp pinpoint directivity
- Provides rich human voice characteristics
Directivity | Super Cardioid / lobar |
Transducer | DC biased condenser |
Frequency range | 50Hz - 20kHz |
Sensitivity (nominal at 1kHz) | 50mV/Pa (-26dB,0dB=1V/Pa) |
Equivalent noise level (A-weighted) | 15dB-A |
Max SPL (1% THD) | 120dB SPL |
Output impedance at 1KHz | 120 ohms |
Powering | +48±4V phantom |
Current consumption | less than 3mA |
Weight | 120g |
Dimensions | 270mm X 19mm (diameter) |
Surface finish | matte black |
Connector | XLR-3M |
