DALE SKU # SENN-EWDXSK3PINQ19

Sennheiser EW-DX SK - Wireless Bodypack Transmitter with 3-Pin Lemo (Q1-9 Band / 470-550 MHz)

Sale price$549.00 Regular price$649.00
Save $100.00
  • Availability:

    In Stock
  • Available for shipment within one business day, or pickup from our Jamaica, NY warehouse during regular business hours.


  • LET OUR TEAM OF EXPERTS ASSIST YOU

    Description

    Compact and versatile bodypack transmitter for use with Evolution Wireless Digital receivers - with 3,5 mm jack or 3-pin connector variants.

    Features:

    • 3,5 mm jack or 3-pin connector variants
    • 10mW RF power with up to 100m/328ft working range
    • Charging contacts for in-device charging with CHG 70N
    • Persistent eInk display - parameters visible on screen even when device is not powered on
    • Programmable mute switch - customize the device depending on your professional needs
    • Extended runtime with lithium ion batteries - up to 12 hours operation time
    • Mic input trim control
    • Metal housing

    What's In The Box:

    • EW-DX SK bodypack transmitter
    • clip
    • batteries (AA)
    • pouch
    • quick guide
    • safety guide
    • manufacturer declaration sheet
    System
    Audio link frequency ranges Q1-9 Band: 470-550 MHz
    R1-9 Band: 520-608 MHz
    V5-7 Band: 941-960 MHz
    Bluetooth¨ Low Energy (BLE) frequency range 2402 - 2480 MHz
    Audio frequency response 20 Hz - 20 kHz (-3 dB) @ 3 dBfs
    Audio THD ? -60 dB for 1 kHz @ -3 dBfs input level
    Dynamic range 134 dB
    System latency 1.9 ms
    Operating temperature -10 ¡C - +55 ¡C (14 ¡F - 131 ¡F)
    Relative humidity 5 - 95 % (non-condensing)
    EW-DX SK (Bodypack Transmitter)
    Input voltage 2.0 - 4.35 V
    Input current < 300 mA
    Power supply 2 AA batteries 1.5 V (alkali manganese) or BA 70 rechargeable battery pack
    Occupied bandwidth 200 kHz
    Transmit power (radiated) Audio link: 10 mW ERP (Range Y1-3: 12 mW ERP)
    LD mode: 10 mW ERP
    BLE: max. 10 mW EIRP
    Dimensions (without antenna) 63.5 x 85 x 20 mm (2.5" x 3.35" x 0.79")
    Weight (without batteries) approx. 115-120 g (0.260,27 - lbs)

    Compact and versatile bodypack transmitter for use with Evolution Wireless Digital receivers - with 3,5 mm jack or 3-pin connector variants.

    Features:

    • 3,5 mm jack or 3-pin connector variants
    • 10mW RF power with up to 100m/328ft working range
    • Charging contacts for in-device charging with CHG 70N
    • Persistent eInk display - parameters visible on screen even when device is not powered on
    • Programmable mute switch - customize the device depending on your professional needs
    • Extended runtime with lithium ion batteries - up to 12 hours operation time
    • Mic input trim control
    • Metal housing

    What's In The Box:

    • EW-DX SK bodypack transmitter
    • clip
    • batteries (AA)
    • pouch
    • quick guide
    • safety guide
    • manufacturer declaration sheet
    System
    Audio link frequency ranges Q1-9 Band: 470-550 MHz
    R1-9 Band: 520-608 MHz
    V5-7 Band: 941-960 MHz
    Bluetooth¨ Low Energy (BLE) frequency range 2402 - 2480 MHz
    Audio frequency response 20 Hz - 20 kHz (-3 dB) @ 3 dBfs
    Audio THD ? -60 dB for 1 kHz @ -3 dBfs input level
    Dynamic range 134 dB
    System latency 1.9 ms
    Operating temperature -10 ¡C - +55 ¡C (14 ¡F - 131 ¡F)
    Relative humidity 5 - 95 % (non-condensing)
    EW-DX SK (Bodypack Transmitter)
    Input voltage 2.0 - 4.35 V
    Input current < 300 mA
    Power supply 2 AA batteries 1.5 V (alkali manganese) or BA 70 rechargeable battery pack
    Occupied bandwidth 200 kHz
    Transmit power (radiated) Audio link: 10 mW ERP (Range Y1-3: 12 mW ERP)
    LD mode: 10 mW ERP
    BLE: max. 10 mW EIRP
    Dimensions (without antenna) 63.5 x 85 x 20 mm (2.5" x 3.35" x 0.79")
    Weight (without batteries) approx. 115-120 g (0.260,27 - lbs)
