Description
The super-cardioid MKH 8050 will give higher attenuation of off-axis sound from the side than its cardioid sister model. It is a good choice for recording soloists, where the requirements for lateral acoustic separation are higher.
Features
- Super-cardioid pick-up pattern
- Modular design
- Wide frequency response 30 to 50.000 Hz
- Symmetrical transducer with 2 backplates providing extremely low distortion
- Extremely low inherent self-noise
- Accurate directional pattern
- Non reflective Nextel coating
- Provides optimum separation of instrument
Current Consumption | 3,3 mA |
Pick Up Pattern | Super cardioid |
Frequency Response | 30 - 50000 Hz |
Sensitivity | 20 mV/Pa (-34 dBV/Pa) |
Nominal Impedance | 25 Ohm |
Min Terminating Impedance | 1000 Ohm |
Equivalent Noise Level | 13 dB |
Max Spl | 142 dB SPL |
Supply Current | 48 V +/- 4 V |
Dimensions | diameter 19 mm, length 41 mm (74 mm including XLR module) |
Weight | 25 g (55 g including XLR module |
The super-cardioid MKH 8050 will give higher attenuation of off-axis sound from the side than its cardioid sister model. It is a good choice for recording soloists, where the requirements for lateral acoustic separation are higher.
Features
- Super-cardioid pick-up pattern
- Modular design
- Wide frequency response 30 to 50.000 Hz
- Symmetrical transducer with 2 backplates providing extremely low distortion
- Extremely low inherent self-noise
- Accurate directional pattern
- Non reflective Nextel coating
- Provides optimum separation of instrument
Current Consumption | 3,3 mA |
Pick Up Pattern | Super cardioid |
Frequency Response | 30 - 50000 Hz |
Sensitivity | 20 mV/Pa (-34 dBV/Pa) |
Nominal Impedance | 25 Ohm |
Min Terminating Impedance | 1000 Ohm |
Equivalent Noise Level | 13 dB |
Max Spl | 142 dB SPL |
Supply Current | 48 V +/- 4 V |
Dimensions | diameter 19 mm, length 41 mm (74 mm including XLR module) |
Weight | 25 g (55 g including XLR module |
