Sennheiser TC BAR S - TeamConnect All In One Conferencing Soundbar
Availability:
Special Order ItemThis item is not stocked and needs to be ordered from the manufacturer. Please contact our sales team for more information.
Sennheiser TC BAR S - TeamConnect All In One Conferencing Soundbar
Sale price$1,299.00
Regular price$1,624.00
Description
The TeamConnect Bar S is the most flexible all-in-one device for small meeting rooms and collaboration spaces. It features 4 microphones and 2 speakers to deliver Trusted Sennheiser Audio Quality to every meeting. The TC Bar S is a true problem solver with benefits like easy setup, brand agnostic integration, easy management and control, high video quality, security and sustainability.
Features:
- Plug and Play Device
Quick start via USB cable - Integrated Beamforming Technology
Freedom of movement and seamless transition among presenters - Flexible Extensions
Using Dante for adding extension mics and/or a 2nd external USB camera - High Video Quality
4K Ultra HD camera equipped with advanced AI features - Full-Range Stereo Speakers
Natural speech and outstanding intelligibility - Built-In DSP
Automatically optimizes room acoustics - Multiple Mounting Options
Wall Mount, VESA Mount, Tabletop or Freestanding - Autoframing and Person Tiling
Features to clearly see everyone in the room - Control Management
Full remote-control access via Sennheiser Control Cockpit - Brand Agnostic Integration
Certifications pending for 3rd party media control systems (Barco, Crestron, Extron, Q-Sys) and platforms (Microsoft Teams, Zoom, Tencent, etc.) - Advanced Security Features
Encrypted control communication and password protected by default for secure content transmission
| General | |
| Dimensions (L x W x H) | 450 x 71 x 76 mm |
| Weight | 1.5 kg |
| Operating temperature range | 0 ¡C to 40 ¡C 32 ¡F to 104 ¡F |
| Storage temperature range | -25 ¡C to 70 ¡C -13 ¡F to 158 ¡C |
| Relative humidity operation | 0 to 75 %, non-condensing |
| Relative humidity storage | 0 to 95 %, non-condensing |
| DC IN | 15 V $, max. 2 A |
| Max. power consumption | 30 W |
| Voltage range PoE (PD) | 42.5 Ð 57.0 V $ (IEEE 802.3at Type 2, PoE+) |
| Power State Information | |
| Standby Mode (all ports deactivated) | ² 0.50 W (Entered after <2.5 hours with no activity on any network port) |
| Networked Standby (all ports activated) | ² 2.00 W (Entered after <20 minutes of inactivity) |
| Networked Standby (all ports activated) | ² 2.00 W |
| Interfaces | |
| HDMI out | HDMI 2.0 |
| USB-C | USB 3.1 (Gen 1) |
| USB-A | USB 3.1 (Gen1) Power output: 5 V $, max. 900 mA |
| Ethernet | 1 x 1000/100/10 Mbit/s (RJ45) Note: Only use network cables with the standard CAT5e (F/STP) or better. |
| DC IN dimension | 5.5 x 2.1 x 10.5 mm |
| Wi-Fi | |
| Standard | IEEE 802.11a /b /g /n /ac |
| Transmission system | SISO (Single-In, Single-Out) |
| Frequency ranges (max. RF output power) | 2412 MHz Ð 2472 MHz (max 20 dBm RF power) 5150 MHz Ð 5350 MHz (max. 23 dBm RF power) 5470 MHz Ð 5725 MHz (max. 23 dBm RF power) 5725 MHz Ð 5850 MHz (max. 14 dBm RF power) |
| Modulation | 64QAM, 16QAM, QPSK, BPSK, CCK, DQPSK, DBPSK |
| Bluetooth¨ | |
| Version | 5.1 |
| Transmission frequency | 2402 MHz - 2480 MHz |
| Modulation | GFSK, ¹/4 DQPSK, 8DPSK |
| Profiles | A2DP, HFP, AVRCP |
| Max. RF output power | 10 dBm |
| Codec | SBC |
| Loudspeaker | |
| Number of speakers | 2 full range loudspeakers with passive radiator |
| Diameter | 50 mm (2") |
| Frequency response | 100 Hz - 18 kHz |
| THD at max. output | < 5 % |
| Amplifier | Class-D |
| Max. SPL (output) | 80 dB SPL |
| Total Audio Power (RMS/PEAK) | 10 W / 20 W |
| Microphones | |
| Transducer principle | MEMS |
| Pick-up pattern | Beamforming Array |
| Number of microphone capsules | 4 |
| Frequency range | 100 Hz to 14.5 kHz |
| Pickup range | 3.5 m |
| Dynamic range | 69 dB (A) |
| Camera | |
| Resolution | UHD 2160p (4K), 1080p, 720p, 960_480, 848_480, 640_480, 640_360, 432_240 |
| Zoom | certified: 2x digital (Microsoft Teams) optional: 3x digital |
| Technology | ePTZ |
| Diagonal field of view | 120¡ |
| Horizontal field of view | 115¡ |
| In The Box | |
| Delivery Includes | TeamConnect Bar S Mounting Bracket Drilling Template Power Supply Unit + Power Cord Remote Control (incl. batteries, bracket / storage) Magnetic Lens Cap HDMI Cable USB-C to USB-A Cable Screws Quick Guide Safety Guide with manufacturer's declarations |
The TeamConnect Bar S is the most flexible all-in-one device for small meeting rooms and collaboration spaces. It features 4 microphones and 2 speakers to deliver Trusted Sennheiser Audio Quality to every meeting. The TC Bar S is a true problem solver with benefits like easy setup, brand agnostic integration, easy management and control, high video quality, security and sustainability.
Features:
- Plug and Play Device
Quick start via USB cable - Integrated Beamforming Technology
Freedom of movement and seamless transition among presenters - Flexible Extensions
Using Dante for adding extension mics and/or a 2nd external USB camera - High Video Quality
4K Ultra HD camera equipped with advanced AI features - Full-Range Stereo Speakers
Natural speech and outstanding intelligibility - Built-In DSP
Automatically optimizes room acoustics - Multiple Mounting Options
Wall Mount, VESA Mount, Tabletop or Freestanding - Autoframing and Person Tiling
Features to clearly see everyone in the room - Control Management
Full remote-control access via Sennheiser Control Cockpit - Brand Agnostic Integration
Certifications pending for 3rd party media control systems (Barco, Crestron, Extron, Q-Sys) and platforms (Microsoft Teams, Zoom, Tencent, etc.) - Advanced Security Features
Encrypted control communication and password protected by default for secure content transmission
| General | |
| Dimensions (L x W x H) | 450 x 71 x 76 mm |
| Weight | 1.5 kg |
| Operating temperature range | 0 ¡C to 40 ¡C 32 ¡F to 104 ¡F |
| Storage temperature range | -25 ¡C to 70 ¡C -13 ¡F to 158 ¡C |
| Relative humidity operation | 0 to 75 %, non-condensing |
| Relative humidity storage | 0 to 95 %, non-condensing |
| DC IN | 15 V $, max. 2 A |
| Max. power consumption | 30 W |
| Voltage range PoE (PD) | 42.5 Ð 57.0 V $ (IEEE 802.3at Type 2, PoE+) |
| Power State Information | |
| Standby Mode (all ports deactivated) | ² 0.50 W (Entered after <2.5 hours with no activity on any network port) |
| Networked Standby (all ports activated) | ² 2.00 W (Entered after <20 minutes of inactivity) |
| Networked Standby (all ports activated) | ² 2.00 W |
| Interfaces | |
| HDMI out | HDMI 2.0 |
| USB-C | USB 3.1 (Gen 1) |
| USB-A | USB 3.1 (Gen1) Power output: 5 V $, max. 900 mA |
| Ethernet | 1 x 1000/100/10 Mbit/s (RJ45) Note: Only use network cables with the standard CAT5e (F/STP) or better. |
| DC IN dimension | 5.5 x 2.1 x 10.5 mm |
| Wi-Fi | |
| Standard | IEEE 802.11a /b /g /n /ac |
| Transmission system | SISO (Single-In, Single-Out) |
| Frequency ranges (max. RF output power) | 2412 MHz Ð 2472 MHz (max 20 dBm RF power) 5150 MHz Ð 5350 MHz (max. 23 dBm RF power) 5470 MHz Ð 5725 MHz (max. 23 dBm RF power) 5725 MHz Ð 5850 MHz (max. 14 dBm RF power) |
| Modulation | 64QAM, 16QAM, QPSK, BPSK, CCK, DQPSK, DBPSK |
| Bluetooth¨ | |
| Version | 5.1 |
| Transmission frequency | 2402 MHz - 2480 MHz |
| Modulation | GFSK, ¹/4 DQPSK, 8DPSK |
| Profiles | A2DP, HFP, AVRCP |
| Max. RF output power | 10 dBm |
| Codec | SBC |
| Loudspeaker | |
| Number of speakers | 2 full range loudspeakers with passive radiator |
| Diameter | 50 mm (2") |
| Frequency response | 100 Hz - 18 kHz |
| THD at max. output | < 5 % |
| Amplifier | Class-D |
| Max. SPL (output) | 80 dB SPL |
| Total Audio Power (RMS/PEAK) | 10 W / 20 W |
| Microphones | |
| Transducer principle | MEMS |
| Pick-up pattern | Beamforming Array |
| Number of microphone capsules | 4 |
| Frequency range | 100 Hz to 14.5 kHz |
| Pickup range | 3.5 m |
| Dynamic range | 69 dB (A) |
| Camera | |
| Resolution | UHD 2160p (4K), 1080p, 720p, 960_480, 848_480, 640_480, 640_360, 432_240 |
| Zoom | certified: 2x digital (Microsoft Teams) optional: 3x digital |
| Technology | ePTZ |
| Diagonal field of view | 120¡ |
| Horizontal field of view | 115¡ |
| In The Box | |
| Delivery Includes | TeamConnect Bar S Mounting Bracket Drilling Template Power Supply Unit + Power Cord Remote Control (incl. batteries, bracket / storage) Magnetic Lens Cap HDMI Cable USB-C to USB-A Cable Screws Quick Guide Safety Guide with manufacturer's declarations |
