Description
The Microflex® Advance™ MXA310 Table Array Microphone. Organizational clarity takes focused discussion. But how can you conference effectively if you can't be heard clearly on the call? The MXA310 maximizes audio quality so voice comes through cleanly.
Features:
- Available in three colors
- LED light ring with configurable colors and brightness control
- Programming-free mute sync with P300
- Discreet design integrates easily into your room. Available with two mounting options: mounts on the table or A310-FM flush mount
- Programmable button offers easy mute control of the MXA310 or a remote device, such as the P300
HOW IT WORKS
The MXA310 integrates smartly into any space. Boardrooms. Huddle rooms. Multi-purpose areas. You can ensure speech is captured accurately and reproduced intelligibly. With Steerable Coverage™ and a low profile design, it removes unnecessary clutter, giving you even more clarity.
WHY IT'S BETTER
-
Focused conversation
- With Steerable Coverage™ and built-in automatic mixing, you can capture every voice with pinpoint accuracy anywhere in the room.
-
No unwanted ambience
- Office HVAC systems can add overpowering background noise to the call. The Shure-exclusive “toroid” polar pattern only captures table-level sound, helping to reduce unwanted distractions from fan or HVAC noise.
-
Dante™ integration
- The MXA310 can easily connect to the vast ecosystem of Shure and third-party networked audio devices.
-
Encryption
- Shure Network Audio Encryption can be enabled when used with the IntelliMix P300 Audio Conferencing Processor or Shure Audio Network Interfaces, which utilize AES-256 technology to protect confidential content.
All specifications measured from cardioid polar pattern. Values for all patterns are within ± 3 dB of these specifications unless otherwise noted | |
Polar Pattern All channels independently adjustable | Cardioid, Hypercardioid, Supercardioid, Toroid, Omnidirectional, Bidirectional |
Connector Type | RJ45 |
Power Requirements | Power over Ethernet (PoE), Class 0 |
Power Consumption | 4W, maximum |
Weight | 362 g (0.8 lbs) |
Dimensions H x W x D | 3.6 x 13.4 x 13.4 cm (1.4 x 5.3 x 5.3 in.) |
control application | HTML5 Browser-based |
Operating Temperature Range | -6.7¡C (20¡F) to 40¡C (104¡F) |
Storage Temperature Range | -29¡C (-20¡F) to 74¡C (165¡F) |
Audio | |
Frequency Response | 100 to 20,000 Hz |
Dante Digital Output | |
Channel Count | 5 total channels (4 independent transmit channels, 1 Automatic mixing transmit channel) |
Sampling Rate | 48 kHz |
Bit Depth | 24 |
Sensitivity at 1 kHz, , -15 dB Gain Setting | -21 dBFS/Pa |
Maximum SPL 1 kHz at 1% THD, -15 dB Gain Setting | 115.2 dB SPL |
Signal-To-Noise Ratio Ref. 94 dB SPL at 1 kHz, -15 dB Gain Setting | |
Cardioid | 75 dB |
Toroid | 67 dB |
Latency Not including Dante latency | <1 ms |
Self Noise -15 dB Gain Setting | |
Cardioid | 19.2 dB SPL-A |
Toroid | 26.8 dB SPL-A |
Dynamic Range -15 dB Gain Setting | |
Cardioid | 96 dB |
Toroid | 90 dB SPL |
Built-in Digital Signal Processing | |
Per Channel | Equalizer (4-band Parametric), Mute, Gain (140 dB range) |
System | Automatic mixing, Low-Cut Filter (-12 dB/octave @150 Hz) |
Networking | |
Cable Requirements | Cat 5e or higher (shielded cable recommended) |
