Sonnet ECHO-EXP-SEL-T3 Echo Express SEL - Thunderbolt 3 1-Slot PCIe Card Expansion Chassis
Availability:
Special Order ItemThis item is not stocked and needs to be ordered from the manufacturer. Please contact our sales team for more information.
Description
Shopping for a new computer? The latest ultra-light notebooks, small form factor and all-in-one Mac®, Windows®, and Linux® computers with Thunderbolt™ ports are slender marvels of engineering that come with a cost—there's nowhere to install PCIe cards that provide additional connectivity and processing capabilities. Sonnet's Echo™ Express SEL is a compact, desktop Thunderbolt™ to PCIe card expansion system that enables you to connect a low-profile PCIe card to any computer with Thunderbolt 3 or Thunderbolt 4 ports.
Echo Express SEL: Low-Profile Desktop Expansion
Echo Express SEL provides a single PCIe card expansion slot in a a light and portable enclosure. It supports nearly every Thunderbolt-compatible, low-profile PCIe 1.1, PCIe 2.0, and PCIe 3.0 cards available. Many of the most popular Thunderbolt-compatible high-speed networking and storage controller cards are a perfect fit, and even the BlueFish 444 Epoch 4K Neutron video card can be accommodated.
Features:
- For Computers with Thunderbolt 3 or Thunderbolt 4 Ports
- 40Gbps Thunderbolt Interface
- Two Thunderbolt 3 Ports
- Quiet, Temperature-Controlled Fan
- Rugged Aluminum Enclosure
- Most Compact Thunderbolt to PCIe Expansion System Available
- Includes 0.7-meter Thunderbolt 3 Cable (unlike other brand of cables, Sonnet's cable provides Thunderbolt 3's full 2750 MB/s bandwidth and supports up to 100W of power delivery)
- Includes Sonnet Designed ThunderLok 3 Connector Retainer Clip (prevents accidental cable disconnections)
- Mac, Windows, and Linux Compatible
- 2-year Product Warranty
- Free Lifetime Customer Technical Support
- Designed and Made in the USA
| Compatibility | |
| Mac Compatibility | Mac (M series) with PCIe cards that have compatible drivers Mac (Intel¨) with Thunderbolt 3 ports Mac (Intel) with a Thunderbolt 2 or Thunderbolt 1 port with an Apple Thunderbolt 3 (USB-C) to Thunderbolt 2 Adapter plus a Thunderbolt 2 cable (both sold separately) macOS¨ 10.12.6+ macOS Ventura compatible |
| Windows Compatibility | Windows computer with Thunderbolt 4 or Thunderbolt 3(1) ports Windows 11 and 10 |
| Linux Compatibility | Linux computer with Thunderbolt 4 or Thunderbolt 3 ports Linux Kernel 5.0+ |
| Hardware | |
| Part Number | ECHO-EXP-SEL-T3 |
| Warranty | 2-year |
| Form Factor | Thunderbolt desktop enclosure |
| External Connectors | Two Thunderbolt ports(2) 12V power port |
| Expansion Slot | One x8 PCIe 3.0 slot x8 mechanical; x4 electrical (Thunderbolt 3 spec) |
| PCIe Cards Supported | One low-profile PCIe card |
| Power Adapter | Universal 60W, 100-240V AC, 50-60 Hz NRTL Certified |
| Operating Temperature | 0¼C to 35¼C (32¼F to 95¼F) |
| Dimensions (WxDxH) | 4 x 8.25 x 2.8 in. (10.3 x 21 x 7.28 cm) |
| Weight | 1.85 lbs (.84 kg) |
| Compliance | RoHS 3 (Directive 2015/863) IEC62368-1 and IEC62368-2 Safety |
| Package Contents | Echo Express SEL Desktop System Universal power adapter Region-specific power cable for US, Australia, Europe, Japan, Switzerland, or UK Thunderbolt 3 cable(3) ThunderLok 3 Thunderbolt connector retainer clip(4) Documentation |
Shopping for a new computer? The latest ultra-light notebooks, small form factor and all-in-one Mac®, Windows®, and Linux® computers with Thunderbolt™ ports are slender marvels of engineering that come with a cost—there's nowhere to install PCIe cards that provide additional connectivity and processing capabilities. Sonnet's Echo™ Express SEL is a compact, desktop Thunderbolt™ to PCIe card expansion system that enables you to connect a low-profile PCIe card to any computer with Thunderbolt 3 or Thunderbolt 4 ports.
Echo Express SEL: Low-Profile Desktop Expansion
Echo Express SEL provides a single PCIe card expansion slot in a a light and portable enclosure. It supports nearly every Thunderbolt-compatible, low-profile PCIe 1.1, PCIe 2.0, and PCIe 3.0 cards available. Many of the most popular Thunderbolt-compatible high-speed networking and storage controller cards are a perfect fit, and even the BlueFish 444 Epoch 4K Neutron video card can be accommodated.
Features:
- For Computers with Thunderbolt 3 or Thunderbolt 4 Ports
- 40Gbps Thunderbolt Interface
- Two Thunderbolt 3 Ports
- Quiet, Temperature-Controlled Fan
- Rugged Aluminum Enclosure
- Most Compact Thunderbolt to PCIe Expansion System Available
- Includes 0.7-meter Thunderbolt 3 Cable (unlike other brand of cables, Sonnet's cable provides Thunderbolt 3's full 2750 MB/s bandwidth and supports up to 100W of power delivery)
- Includes Sonnet Designed ThunderLok 3 Connector Retainer Clip (prevents accidental cable disconnections)
- Mac, Windows, and Linux Compatible
- 2-year Product Warranty
- Free Lifetime Customer Technical Support
- Designed and Made in the USA
| Compatibility | |
| Mac Compatibility | Mac (M series) with PCIe cards that have compatible drivers Mac (Intel¨) with Thunderbolt 3 ports Mac (Intel) with a Thunderbolt 2 or Thunderbolt 1 port with an Apple Thunderbolt 3 (USB-C) to Thunderbolt 2 Adapter plus a Thunderbolt 2 cable (both sold separately) macOS¨ 10.12.6+ macOS Ventura compatible |
| Windows Compatibility | Windows computer with Thunderbolt 4 or Thunderbolt 3(1) ports Windows 11 and 10 |
| Linux Compatibility | Linux computer with Thunderbolt 4 or Thunderbolt 3 ports Linux Kernel 5.0+ |
| Hardware | |
| Part Number | ECHO-EXP-SEL-T3 |
| Warranty | 2-year |
| Form Factor | Thunderbolt desktop enclosure |
| External Connectors | Two Thunderbolt ports(2) 12V power port |
| Expansion Slot | One x8 PCIe 3.0 slot x8 mechanical; x4 electrical (Thunderbolt 3 spec) |
| PCIe Cards Supported | One low-profile PCIe card |
| Power Adapter | Universal 60W, 100-240V AC, 50-60 Hz NRTL Certified |
| Operating Temperature | 0¼C to 35¼C (32¼F to 95¼F) |
| Dimensions (WxDxH) | 4 x 8.25 x 2.8 in. (10.3 x 21 x 7.28 cm) |
| Weight | 1.85 lbs (.84 kg) |
| Compliance | RoHS 3 (Directive 2015/863) IEC62368-1 and IEC62368-2 Safety |
| Package Contents | Echo Express SEL Desktop System Universal power adapter Region-specific power cable for US, Australia, Europe, Japan, Switzerland, or UK Thunderbolt 3 cable(3) ThunderLok 3 Thunderbolt connector retainer clip(4) Documentation |
