Sound Devices MixPre 10 II Portable 10-Track Field Recorder
Availability:
Special Order ItemThis item is not stocked and needs to be ordered from the manufacturer. Please contact our sales team for more information.
Description
If you record field audio, sound effects, audio for film, live music, or are just starting your audio journey, the MixPre-10 II is for you! With eight crystal-clear, ultra low-noise Kashmir preamps, you can record multiple actors, multiple podcasters, or audio for film with superior quality – all the way up to a 32-bit float bit depth and a 192 kHz sample rate. This newest generation of Sound Devices’ award-winning MixPre Series has been redesigned for increased performance and an astounding 142 dB of dynamic range.
Your MixPre-10 II is highly customizable to your needs. Record internally to a compatible SD card on set or stream your podcast over USB to your computer at home. Power with wall power, or record in the middle of nowhere with AA or Sony L-mount batteries. Adjust limiters, bit depth, sample rates, gain, pan, low-cut, phase inversion and phantom power to your liking. Stay in sync with your camera using the internal timecode generator, or feed timecode in via HDMI, Aux In, or BNC. The choice is yours!
Professionals love the flexibility of the MixPre Series. Don’t need all those options? Basic mode has you covered.
Your MixPre-10 II is rugged, lightweight, and small, so you can throw it in a bag or mount it to a tripod or camera – or get situated on set with the Wingman App and one of four supported USB control surfaces. With the superior sound and build quality that you can expect from the industry leader in production audio recording, your MixPre-10 II can capture audio for any application.
Are you a songwriter or musician? Buy the Musician Plugin to easily create a song using your MixPre-10 II as a standalone recorder or USB interface. Use onboard features like overdub, bounce, reverb, and tracking to a metronome. Create Music Projects to lay down backing tracks and use them live or at home for writing or practicing. Capturing your song ideas has never been easier! While in Music Mode, the MixPre-10 II is limited to eight simultaneous live inputs.
Download the free Ambisonics Plugin to record in 360° audio and monitor binaurally with an ambisonic microphone like the Sennheiser AMBEO and your MixPre-10 II.
Features:
- Eight ultra-low-noise Kashmir microphone preamps with adjustable limiters capture high quality audio in the field, on set, or with a computer.
- Create a mix using the built-in 10 x 4 portable mixer.
- Record up to 12 tracks to an SD card and backup to a USB thumb drive.
- 12-in, 4-out USB audio interface streams to your computer via USB-C.
- Choose bit depths from 16 to 32-bit float, and sampling rates from 44.1 kHz to 192 kHz.
- Internal LTC timecode generator. Timecode In/Out via BNC or Aux In/Stereo Out.
- Timecode and record triggering via HDMI.
- USB-A for control surfaces, keyboards, and auto-copy to USB drive.
- In-unit ISO mixing, gain, pan, low-cut, phase inversion, and phantom power.
- Sunlight-readable color touch screen and LED metering.
- Lightweight, durable, and small: perfect for bag use, mobile recording, or a home studio.
- Powerful 300 mW+300 mW headphone amp allows clear and accurate reference of audio.
- Includes a MX-8AA Battery Sled (batteries not included), XL-WPH3 AC Power Supply, and USB-C to USB-C cable.
- Customize with plugins from the Plugin Store.
| Audio Inputs | |
| Frequency Response | 10Hz to 80kHz +/- 0.5dB re 1kHz @ 192kHz sample rate |
| THD + Noise | 0.005% max (@1kHz, 22-22kHz BW, gain=20dB, -10dBu in) |
| ADC | 32 bit precision; 142dB dynamic range min (A-weighted, gain=10dB, fader=0dB) |
| Equivalent Input Noise | -130dBV (-128dBu) max (A-weighting, gain=76dB, 150 ohm source impedance) |
| Inputs | Mic: XLR active-balanced; 4k input Line: XLR active-balanced; 4k input Aux/Mic in: 3.5mm TRS, 2-channel unbalanced; 100k input Line: _-inch TRS active-balanced; 4k input USB Audio: 4 channels All inputs fully RF-filtered and overload protected. |
| Gain | Mic input: +6dB to +76dB Line input: -20dB to +30dB Fader: -inf to +20dB Headphone: -inf to +20dB Total, Mic-to-recording (max): +96dB Aux In (Mic): Gain = +10dB to +40dB Aux In (Line): Gain = -10dB to +20dB Total Aux Gain including Fader (Mic-to-recording): +60dB |
| Maximum Input Level | Mic XLR: +14dBu (limiters on or off) Line XLR/_-inch: +28dBu (limiters on or off) Aux In (Mic): -10dBu Aux In (Line): +10dBu |
| Low Cut Filters | 40Hz to 160Hz (adjustable), 18 dB/oct. First stage analog, subsequent stages digital. |
| Microphone Powering | Mic XLRs: 48V via 6.8k resistors, 10mA each Mic 3.5mm: 3V @ 3k source |
| Limiters | Limiter at all gain stages, range> 40dB. First stage analog, subsequent stages digital. Adjustable Threshold, Ratio, and Release. |
| Audio Outputs | |
| DAC feeding Stereo Out, Headphone Out | 32 bit precision; 115dB dynamic range (A-weighted) |
| L/R Out | TA3 2-channel balanced, 1.1K max output impedance, +18 dBu max output level |
| X1/X2 Out | 3.5mm TRS stereo unbalanced, 500 ohm output impedance, +7.8dBu max output level |
| Headphones Out | 3.5mm TRS stereo unbalanced, 300mW + 300mW, for use with any impedance headphones |
| USB | Audio Interface (USB-C): 12-in/4-out; 44.1 to 96 kHz; 16/24-bit; Class-compliant USB 2.0 high speed or ASIO¨ driver (supplied via download) Mass Storage (USB-C): USB 2.0 high speed Keyboard (USB-A): Text entry and control Thumbdrive (USB-A): Manual or auto-copy to drive Midi Control Surface (USB-A) |
| Recording | |
| Maximum Record Tracks | 12 Tracks: Stereo mix + 10 ISOs |
| Sampling Frequency | 44.1 kHz 47.952 kHz 48 kHz 48.048 kHz 96 kHz 192 kHz |
| Bit Depth | 16 24 32 Float |
| Recording Storage | Type: SD, SDXC, SDHC Card (USB thumbdrive, copy only) Max Storage Size: 512 GB (SDXC) Card format: exFAT |
| File Types | Polyphonic WAV |
| Timecode | |
| Timecode Modes | Free Run Time of Day (file stamped w/current ToD) Rec Run Ext LTC (file stamped w/incoming LTC on BNC or Aux 3.5mm) Camera TC (file stamped w/incoming TC from cameras that output TC) |
| Timecode Frame Rates | Auto-detects (fps): 23.98 (same as 23.976) 24 25 29.97DF 29.97ND 30 30DF |
| Sync Source | Internal, Word Clock, Ext LTC BNC In (TC In) Switchable between Timecode (default) or Word Clock Input Timecode: 20k ohm impedance, 0.3 V - 3.0 V p-p (Ð17 dBu - +3 dBu) Word Clock: 10k ohm impedance, 1.5V p-p |
| BNC Out (TC Out) | Switchable between Timecode (default) or Word Clock Output Timecode: 1k ohm impedance, 3.0V p-p (+12 dBu) Word Clock: 75 ohm impedance, 5V p-p |
| HDMI | TC Reader via HDMI Remote Control Bluetooth LE: Wireless control using Wingman app HDMI (micro): Auto-record start/stop trigger from cameras that output record flag over HDMI Timecode: Auto-record start/stop trigger via Aux In timecode |
| Touch Screen | 320x256; 1.6-inch, color, sunlight-viewable IPS LCD |
| Power | AA Batteries: 8x AA sled (included). NiMH recommended L-Mount: Optional sled for 2x (hot-swappable) Li-ion batteries AC Adapter: XL-WPH3 (included): Universal, 45 W in-line AC-to-DC power supply Hirose 4-pin DC plug, with detachable IEC power cord. 100-240, 50/60Hz |
| Environmental | Operating: -20¡C to 60¡C, 0 to 90% relative humidity; (non-condensing) Storage: -40¡C to 85¡C |
| Dimensions | 36 mm x 206 mm x 175 mm (H x W x D); 1.375Ó x 8.125Ó x 6.875Ó |
| Weight | 0.91 kg; 32.1 oz. (unpackaged, without batteries) |
