Sound Devices MixPre-6 II Portable 6-Channel Field Recorder

  • Dale #:

    SODE-9832
  • Availability:

    Not in Stock - Reserve Yours
  • This item is not in stock and needs to be ordered from the manufacturer. Your payment will be charged after completing checkout. We will strive to ship as soon as possible, pending availability.

Description

If you record field audio, sound effects, podcasts, voice-overs, music, audio for film, or are just starting your audio journey, the MixPre-6 II is for you! With four crystal-clear, ultra low-noise Kashmir preamps, you can record multiple actors, multiple podcasters, or audio for film with superi... Read More

Shipping Charges Apply

Have a Question?

Call Toll Free: 888-462-7828 Live Chat Email Us

Suggested Accessories

Description

If you record field audio, sound effects, podcasts, voice-overs, music, audio for film, or are just starting your audio journey, the MixPre-6 II is for you! With four crystal-clear, ultra low-noise Kashmir preamps, you can record multiple actors, multiple podcasters, or audio for film with superior quality – all the way up to a 32-bit float bit depth and a 192 kHz sample rate. This newest generation of Sound Devices’ award-winning MixPre Series has been redesigned for increased performance and an astounding 142 dB of dynamic range.

Your MixPre-6 II is highly customizable to your needs. Record internally to a compatible SD card on set or stream your podcast over USB to your computer at home. Power with your computer, wall power, or record in the middle of nowhere with AA or Sony L-mount batteries. Adjust limiters, bit depth, sample rates, gain, pan, low-cut, phase inversion and phantom power to your liking. Trigger your camera with the internal timecode generator, or feed timecode in via HDMI or Aux In. The choice is yours!

Professionals love the flexibility of the MixPre Series. Don’t need all those options? Basic mode has you covered.

Your MixPre-6 II is rugged, lightweight, and small, so you can throw it in a bag or mount it to a tripod or camera – or get situated on set with our Wingman App and one of our four supported USB control surfaces. With the superior sound and build quality that you can expect from the industry leader in production audio recording, your MixPre-6 II can capture audio for any application.

Customize With Plugins
Are you a songwriter or musician? Buy the Musician Plugin to easily create a song using your MixPre-6 II as a standalone recorder or USB interface. Use onboard features like overdub, bounce, reverb, and tracking to a metronome. Create Music Projects to lay down backing tracks and use them live or at home for writing or practicing. Capturing your song ideas has never been easier! While in Music Mode, the MixPre-6 II is limited to six simultaneous live inputs.

Download the free Ambisonics Plugin to record in 360° audio and monitor binaurally with an ambisonic microphone like the Sennheiser AMBEO and your MixPre-6 II.

Features:

  • Four ultra-low-noise Kashmir microphone preamps with adjustable limiters capture high quality audio in the field, on set, or with a computer.
  • Create a mix using the built-in 6 x 2 portable mixer.
  • Record up to 8 tracks to an SD card and backup to a USB thumb drive.
  • 8-in, 4-out USB audio interface streams to your computer via USB-C.
  • Choose bit depths from 16 to 32-bit float, and sampling rates from 44.1 kHz to 192 kHz.
  • Internal LTC timecode generator. Timecode In/Out via Aux In/Stereo Out.
  • Timecode and record triggering via HDMI.
  • USB-A for control surfaces, keyboards, and auto-copy to USB drive.
  • In-unit ISO mixing, gain, pan, low-cut, phase inversion, and phantom power.
  • Sunlight-readable color touch screen and LED metering.
  • Lightweight, durable, and small: perfect for bag use, mobile recording, or a home studio.
  • Powerful 300 mW+300 mW headphone amp allows clear and accurate reference of audio.
  • Includes a MX-4AA Battery Sled (batteries not included), MX-PSU AC Power Supply, and USB-C to USB-C cable.
  • Customize with plugins from the Plugin Store.

More +

Product Specs

Audio Inputs
Frequency Response 10Hz to 80kHz +/- 0.5dB re 1kHz @ 192kHz sample rate
THD + Noise 0.005% max (@1kHz, 22-22kHz BW, gain=20dB, -10dBu in)
ADC 32 bit precision; 142 dB dynamic range min (A-weighted, gain=10dB, fader=0dB)
Equivalent Input Noise -130dBV (-128dBu) max (A-weighting, gain=76dB, 150 ohm source impedance)
Inputs Mic: XLR active-balanced; 4k input
Line: XLR active-balanced; 4k input
Aux/Mic in: 3.5mm TRS, 2-channel unbalanced; 100k input
Line: _-inch TRS active-balanced; 4k input
USB Audio: 4 channels
All inputs fully RF-filtered and overload protected.
Gain Mic input: +6dB to +76dB
Line input: -20dB to +30dB
Fader: -inf to +20dB
Headphone: -inf to +20dB
Total, Mic-to-recording (max): +96dB
Aux In (Mic): Gain = +10dB to +40dB
Aux In (Line): Gain = -10dB to +20dB
Total Aux Gain including Fader (Mic-to-recording): +60dB
Maximum Input Level Mic XLR: +14dBu (limiters on or off)
Line XLR: +28dBu (limiters on or off)
Aux In (Mic): -10dBu
Aux In (Line): +10dBu
Low Cut Filters 40Hz to 160Hz (adjustable), 18 dB/oct. First stage analog, subsequent stages digital.
Microphone Powering Mic XLRs: 48V via 6.8k resistors, 10mA each
Mic 3.5mm: 3V @ 3k source
Limiters Limiter at all gain stages, range> 40dB. First stage analog, subsequent stages digital. Adjustable Threshold, Ratio, and Release.
Audio Outputs
DAC feeding Stereo Out, Headphone Out 32 bit precision; 115dB dynamic range (A-weighted)
Stereo Out 3.5mm TRS stereo unbalanced, 500 ohm output, +7.8dBu max output level
Headphones Out 3.5mm TRS stereo unbalanced, 300mW + 300mW, for use with any impedance headphones
USB Audio Interface (USB-C): 8-in/4-out; 44.1 to 96 kHz; 16/24-bit; Class-compliant USB 2.0 high speed or ASIO¨ (supplied via download)
Mass Storage (USB-C): USB 2.0 high speed
Keyboard (USB-A): Text entry and control
Thumbdrive (USB-A): Manual or auto-copy to drive
Midi Control Surface (USB-A)
Recording
Maximum Record Tracks 8 Tracks: Stereo mix + 6 ISOs
Sampling Frequency 44.1 kHz
47.952 kHz
48 kHz
48.048 kHz
96 kHz
192 kHz
Bit Depth 16
24
32 Float
Recording Storage Type: SD, SDXC, SDHC Card (USB thumbdrive, copy only)
Max Storage Size: 512 GB (SDXC)
Card format: exFAT
File Type Polyphonic WAV
Timecode
Timecode Modes Free Run
Time of Day (file stamped w/current ToD)
Rec Run
Ext LTC (file stamped w/incoming LTC on 3.5mm Aux In)
Camera TC (file stamped w/incoming TC from cameras that output TC)
Timecode Frame Rates Auto-detects (fps): 23.98 (same as 23.976)
24
25
29.97DF
29.97ND
30
30DF
3.5 mm Aux In Timecode Input Timecode: 20k ohm impedance, 0.3 V - 3.0 V p-p (Ð17 dBu - +3 dBu)
3.5 mm Stereo Out Timecode Output Timecode: 1k ohm impedance, 3.0V p-p (+12 dBu)
HDMI TC Reader via HDMI
Remote Control
Bluetooth LE: Wireless control using Wingman app
HDMI (micro): Auto-record start/stop trigger from cameras that output record flag over HDMI
Timecode: Auto-record start/stop trigger via Aux In timecode
Touch Screen 320x256; 1.6-inch, color, sunlight-viewable IPS LCD
Power AA Batteries: 4x AA sled (included); 8x AA sled (optional accessory). NiMH recommended
From computer: Bus-powered via USB-C port; optional MX-USBY cable, connects one USB-C to two USB-A ports
AC Adapter: MX-PSU (included) Power supply wall adapter w/ USB-C connector; 15W; has 4 adapter plugs for US, UK, AU / Europe
L-Mount: Optional sled for 2x (hot-swappable) Sony L-type Li-ion batteries
Environmental Operating: -20¡C to 60¡C, 0 to 90% relative humidity; (non-condensing)
Storage: -40¡C to 85¡C
Dimensions 36mm x 166 mm x 118 mm (H x W x D); 1.40Ó x 6.53Ó x 4.65Ó
Weight .56 kg; 19.9 oz. (unpackaged, without batteries)
