Soundtube CM62-EZS-II-WH - Two-Way 6.5-Inch In-Ceiling Loudspeaker with Short Can (White)

  • Dale #:

    SOTU-CM62EZSIIWH
  • Availability:

    Not in Stock - Reserve Yours
  • This item is not in stock and needs to be ordered from the manufacturer. Your payment will be charged after completing checkout. We will strive to ship as soon as possible, pending availability.

Description

The CM62-EZs-II is a 6.5-inch, coaxial, two-way, blind-mount, in-ceiling speaker which delivers true high efficiency and performance across the operating bandwidth. By incorporating a 6.5-inch treatedfiber driver with cloth surround in a sealed drawn-steel backcan, this speaker delivers maximum f... Read More

Free Shipping (Continental US)

Have a Question?

Call Toll Free: 888-462-7828 Live Chat Email Us

Suggested Accessories

Description

The CM62-EZs-II is a 6.5-inch, coaxial, two-way, blind-mount, in-ceiling speaker which delivers true high efficiency and performance across the operating bandwidth. By incorporating a 6.5-inch treatedfiber driver with cloth surround in a sealed drawn-steel backcan, this speaker delivers maximum frequency response (75 Hz - 22 kHz, - 10 dB) in a compact design.

The CM62-EZs-II features a ceramic input terminal that accepts up to 10 gauge plenum rated signal wire and includes a thermal fuse for use in voice alarm applications subject to EU regulations EN60849 and BS5839-8. Mounting hardware is included and features a constant-tension winged mounting system with a 21-gauge "fullmetal" steel tile bridge, ensuring rapid and secure installation in any sheetrock or drop-tile application. For easy ordering, stocking and installation, this series includes a color-coded (green) tile bridge and a six-position tap switch for 25-, 70.7- and 100-volt applications with transformer bypass position.

Features:

  • Engineered for applications with limited plenum space, incorporating a SoundTube-specific shallow backcan with an installed depth of only 3.5 inches.
  • One 6.50 in (165.0 mm) treated fiber woofer with cloth surround and one 1.00 in (25.4 mm) silk dome tweeter.
  • Easy-access six-position tap switch for 25/70.7/100-volt and 16 ohm transformer bypass position allows for easy ordering, stocking and installation.
  • Reduced amplification costs with maximum efficiency including 90.5 dB sensitivity and 16 ohm impedance.
  • Ceramic input terminal accepts up to 10 gauge plenum rated signal wire and includes thermal fuse.
  • Suitable for use in voice alarm applications subject to EU regulations EN60849 and BS5839-8.
  • Superior voice intelligibility with a 10 kHz coverage angle of 80¡ (independently verified).
  • Cost-effective 16 ohm settings allows for the use of multiples of two, four, or six speakers in a system using a standard amplifier without a transformer.
  • Incorporates a painted steel grille for lasting durability.
  • Adaptable to material thicknesses ranging from 0.04 inch (0.9 mm) - 1.60 inch (40.6 mm).
  • UL 1480 (UEAY) and 2043, cUL, CE (EMC Directive 89/366/EEC, EN55020, EN55013) approved.
  • High-quality black or white paint finish. Custom colors available. Grille is paintable (custom colors are not EN54-24 2008 certified).
  • Included accessories: Tile bridge, ULlisted 0.5-inch flex conduit clamp, paint shield and two wire nuts.
  • Optional accessories: Color-coded (green) pre-construction bracket (AC-CMEZ6/8- PCB) ; junction box (AC-CM-EZ-JBOX).


Applications

Developed specifically for the paging and background music applications where cost, quality and fit are paramount, the CM62-EZs-II is ideal for hotels, retail stores, restaurants, airports, churches (under eave) or boardrooms. Indeed, the entire CM-EZ-II series is engineered for installations where high efficiency and rapid installation are critical attributes. For applications requiring additional bass response, SoundTube's CM1001dT subwoofer provides true low-end response down to 41 Hz.

More +

Product Specs

Frequency Response (-10 dB) 75 Hz Ð 22 kHz
Sensitivity 90.5 dB
Power Capacity RMS 50 W
Max SPL dB @ 1 M 107.5 dB
Nominal Impedance 16 ohm
Transformer Options 25 / 70.7 / 100 Volt
16 Ohm direct
Tweeter 1_ Silk
Woofer 6.5_ Treated fiber
Connections 4 position ceramic terminal strip
Visible Height 8.6 mm (0.34 in)
Visible Diameter 298.5 mm (11.75 in)
Backcan Height 95.3 mm (3.75 in)
Backcan Diameter 245.6 mm (9.67 in)
Weight 3.2 kg (7.0 lbs)
Shipping Weight 3.6 kg (8.0 lbs)
Optional Accessories Color-coded (green) pre-construction bracket (AC-CMEZ6/8-PCB)
Junction box (AC-CM-EZ-JBOX)
Colors Black / White / Custom
