Soundtube SM1001-BK - 10-Inch Install Subwoofer with Passive Radiator (Black)
Availability:
Special Order ItemThis item is not stocked and needs to be ordered from the manufacturer. Please contact our sales team for more information.
Description
The SM1001 is a 10Ó subwoofer with a passive radiator to generate deep, high output bass response. The SM1001 uses a proprietary 10-inch high-excursion, ultra-long throw mica-graphite polypropylene driver and a downward-firing bass radiator. The efficient long throw designs are superbly linear, making the SM1001 an ideal complement to any music system. The driver is attached to a 1.5-inch MDF baffle to eliminate cabinet distortion The SM1001 is a great addition to background and foreground audio installations where high-quality, true bass response and rapid installation are critical. Aerobic rooms, retail stores, restaurants, nightclubs, bars, theme parks, arenas, ballrooms, and churches are all ideal fits for this subwoofer.
Features:
- 10Ó high excursion subwoofer
- 10Ó high excursion passive radiator
- Solid cabinet with textured paint finish.
- Powder-coated steel grilles provide lasting durability.
- Included accessory: Euroblock connector, Safety cable and forged eyebolt.
- Optional accessories: Surface mount bracket (AC-SM1001p-S), corner mount bracket (AC-SM1001p-C).
| Color | Black |
| UPC | 644216228706 |
| Manufacturer | SoundTube |
| Manufacturer's Category | Subwoofer |
| Depth | 12.5 in / 317.5 mm |
| Height | 15.5 in / 393.7 mm |
| Width/Diameter | 24.5 in / 622.3 mm |
| Shipping Weight | 32 lbs / 14.5 kg |
| Enclosure Properties | MDF |
| Included Accessories | Euroblock |
| Optional Accessories | Corner Mount Bracket (AC-SM1001p-C), Surface Mount Bracket (AC-SM1001p-S) |
| Source Inputs | 2 Pin 5.08mm Euroblock |
| TAA Compliant (Trade America) | Yes |
| BAA Compliant (Made in USA) | Yes |
| Frequency Response (± 3 dB) | 26 - 150 Hz |
| Grille Properties | Powder-Coated, Steel |
| Max. Continuous Power RMS | 175 W |
| Max SPL @ 1M | 104 dB RMS, 116 dB Peak |
| Max. Program Power | 350 W |
| Nominal Impedance (_ Ohms) | 4 _ |
| Subwoofer Driver | (1) 10" Active / (1) 10" Passive Mica-Graphite Polypropylene |
| Sensitivity dB @ 1W/1M | 88 dB |
| Sensitivity dB @ 2.83V/1M | 91 dB |
The SM1001 is a 10Ó subwoofer with a passive radiator to generate deep, high output bass response. The SM1001 uses a proprietary 10-inch high-excursion, ultra-long throw mica-graphite polypropylene driver and a downward-firing bass radiator. The efficient long throw designs are superbly linear, making the SM1001 an ideal complement to any music system. The driver is attached to a 1.5-inch MDF baffle to eliminate cabinet distortion The SM1001 is a great addition to background and foreground audio installations where high-quality, true bass response and rapid installation are critical. Aerobic rooms, retail stores, restaurants, nightclubs, bars, theme parks, arenas, ballrooms, and churches are all ideal fits for this subwoofer.
Features:
- 10Ó high excursion subwoofer
- 10Ó high excursion passive radiator
- Solid cabinet with textured paint finish.
- Powder-coated steel grilles provide lasting durability.
- Included accessory: Euroblock connector, Safety cable and forged eyebolt.
- Optional accessories: Surface mount bracket (AC-SM1001p-S), corner mount bracket (AC-SM1001p-C).
| Color | Black |
| UPC | 644216228706 |
| Manufacturer | SoundTube |
| Manufacturer's Category | Subwoofer |
| Depth | 12.5 in / 317.5 mm |
| Height | 15.5 in / 393.7 mm |
| Width/Diameter | 24.5 in / 622.3 mm |
| Shipping Weight | 32 lbs / 14.5 kg |
| Enclosure Properties | MDF |
| Included Accessories | Euroblock |
| Optional Accessories | Corner Mount Bracket (AC-SM1001p-C), Surface Mount Bracket (AC-SM1001p-S) |
| Source Inputs | 2 Pin 5.08mm Euroblock |
| TAA Compliant (Trade America) | Yes |
| BAA Compliant (Made in USA) | Yes |
| Frequency Response (± 3 dB) | 26 - 150 Hz |
| Grille Properties | Powder-Coated, Steel |
| Max. Continuous Power RMS | 175 W |
| Max SPL @ 1M | 104 dB RMS, 116 dB Peak |
| Max. Program Power | 350 W |
| Nominal Impedance (_ Ohms) | 4 _ |
| Subwoofer Driver | (1) 10" Active / (1) 10" Passive Mica-Graphite Polypropylene |
| Sensitivity dB @ 1W/1M | 88 dB |
| Sensitivity dB @ 2.83V/1M | 91 dB |
