Soundtube SM590i-II-WX-WH - Two-Way 5.25-Inch Outdoor Surface Mount Speaker (White)
Availability:
Special Order ItemThis item is not stocked and needs to be ordered from the manufacturer. Please contact our sales team for more information.

Description
SoundTube¨'s WX Weather Guard technology utilizes a dual layer hydrophobic material inside the speaker grille and an aluminum grille with powder-coat finish to keep water from the drivers and internal electronics in even the most extreme weather conditions. The speaker includes a higher power output for long throw and high SPL requirements as well as one 5.25-inch polypropylene woofer and one 1.0 inch, tractrix horn-loaded, convex aluminum dome tweeter in a ported enclosure. SM590I-II-WX has a 87.0 dB average sensitivity which offers high output capabilities and reduced amplification costs. The speaker has an easy access, six-position selectable tap switch for 25-, 70.7- and 100-volt applications with transformer bypass position and utilizes patented ZeroReflectionªÊenclosure technology for optimal sound reproduction and cabinet rigidity. Utilizing the new SM590I-II StealthªÊbracket mounting systems as well as vertical and horizontal pivoting allow the SM590I-II-WX to be aimed anywhere within the installation space and the low profile enclosure design keeps the speaker close to the wall.
Features:
- High-power output (106 dB) for long throw and high SPL requirements.
- One 5.25Ó (133 mm) polypropylene woofer and one 1Ó (25.4 mm) Tractrix profile horn convex titanium dome tweeter mounted to a proprietary cast-aluminum baffle and heat sink.
- 87 dB average sensitivity offers high output capabilities and reduced amplification costs.
- Includes weatherized components for indoor and outdoor applications.
- Easy access, six-position selectable tap switch for 25, 70.7, and 100 V applications with transformer bypass position.
- Aluminum grille with powder-coat finish.
- Includes the new SM590i-II Stealthª bracket mounting system
- Vertical and horizontal pivoting offer precision aiming for indoor and outdoor applications.
- Pan and tilt capabilities
- CE approved.
- High-quality black or white paint finish.
| Color | White |
| UPC | 644216203901 |
| Manufacturer | SoundTube |
| Manufacturer's Category | SMi Surface Mount |
| Height | 11.4 in / 289.6 mm |
| Width/Diameter | 8.36 in / 212.3 mm |
| Shipping Weight | 10.5 lbs / 4.76 kg |
| Carton Height | 14 in / 355.6 mm |
| Carton Length | 13.5 in / 342.9 mm |
| Carton Width | 10.5 in / 266.7 mm |
| Certifications | CE, IP55, RoHS |
| Enclosure Properties | ABS Glass Fiber Reinforced, Injection Molded, Ported |
| Enclosure Volume | 349.6 cu in / 5728.92 cu cm |
| Included Accessories | Euroblock, Mounting Hardware, Safety Cable, Terminal Weather Boot |
| Optional Accessories | Black Grille (GRL-SM500-II-WX-BK)|10" Safety Cable (AC-SM-SC10)|Black Mounting Bracket (AC-SM5-II-WP-BK)|Connector (EUROBLOCK)|Black Weatherboot (WEATHERBOOT-S-BK) |
| Source Inputs | 4 Pin 5.08mm Euroblock |
| IP Rating | IP44 |
| TAA Compliant (Trade America) | No |
| BAA Compliant (Made in USA) | No |
| Crossover Frequency | 3.0 kHz |
| Directivity Factor (Q) (Averaged 100Hz - 10kHz, @ 2kHz) | 5.7 and 9.3 |
| Directivity Index (DI) dB (Averaged 100Hz - 10kHz, @ 2kHz) | 6.0dB and 9.7dB |
| Frequency Response (± 10 dB) | 69 Hz - 22 kHz |
| Frequency Response (± 3 dB) | 100 Hz - 22 kHz |
| Grille Properties | Aluminum, Powder-Coated, Weatherproof |
| Low Frequency Voice Coil | 1 in / 25.4 mm |
| Max. Continuous Power RMS | 80W |
| Max. Program Power | 160 W |
| Minimum Impedance (_ Ohms) | 7 _ |
| Mounting Depth | 10.48 in / 266.2 mm |
| Network Type: High Pass | 12 dB per octave 2nd order |
| Nominal Impedance (_ Ohms) | 8 _ |
| Tweeter Driver | 1" Convex Titanium Horn-Loaded |
| Woofer Driver | 5.25" Polypropylene |
| Sensitivity dB @ 1W/1M | 87 dB |
| Sensitivity dB @ 2.83V/1M | 87 dB |
| Tap Selector | Rotary Switch |
| Transformer Options | 25 / 70.7 / 100 V, 4 Ohm direct |
| Transformer Taps Max. Setting (25V/70.7V/100V) | 8W/64W/64W |
SoundTube¨'s WX Weather Guard technology utilizes a dual layer hydrophobic material inside the speaker grille and an aluminum grille with powder-coat finish to keep water from the drivers and internal electronics in even the most extreme weather conditions. The speaker includes a higher power output for long throw and high SPL requirements as well as one 5.25-inch polypropylene woofer and one 1.0 inch, tractrix horn-loaded, convex aluminum dome tweeter in a ported enclosure. SM590I-II-WX has a 87.0 dB average sensitivity which offers high output capabilities and reduced amplification costs. The speaker has an easy access, six-position selectable tap switch for 25-, 70.7- and 100-volt applications with transformer bypass position and utilizes patented ZeroReflectionªÊenclosure technology for optimal sound reproduction and cabinet rigidity. Utilizing the new SM590I-II StealthªÊbracket mounting systems as well as vertical and horizontal pivoting allow the SM590I-II-WX to be aimed anywhere within the installation space and the low profile enclosure design keeps the speaker close to the wall.
Features:
- High-power output (106 dB) for long throw and high SPL requirements.
- One 5.25Ó (133 mm) polypropylene woofer and one 1Ó (25.4 mm) Tractrix profile horn convex titanium dome tweeter mounted to a proprietary cast-aluminum baffle and heat sink.
- 87 dB average sensitivity offers high output capabilities and reduced amplification costs.
- Includes weatherized components for indoor and outdoor applications.
- Easy access, six-position selectable tap switch for 25, 70.7, and 100 V applications with transformer bypass position.
- Aluminum grille with powder-coat finish.
- Includes the new SM590i-II Stealthª bracket mounting system
- Vertical and horizontal pivoting offer precision aiming for indoor and outdoor applications.
- Pan and tilt capabilities
- CE approved.
- High-quality black or white paint finish.
| Color | White |
| UPC | 644216203901 |
| Manufacturer | SoundTube |
| Manufacturer's Category | SMi Surface Mount |
| Height | 11.4 in / 289.6 mm |
| Width/Diameter | 8.36 in / 212.3 mm |
| Shipping Weight | 10.5 lbs / 4.76 kg |
| Carton Height | 14 in / 355.6 mm |
| Carton Length | 13.5 in / 342.9 mm |
| Carton Width | 10.5 in / 266.7 mm |
| Certifications | CE, IP55, RoHS |
| Enclosure Properties | ABS Glass Fiber Reinforced, Injection Molded, Ported |
| Enclosure Volume | 349.6 cu in / 5728.92 cu cm |
| Included Accessories | Euroblock, Mounting Hardware, Safety Cable, Terminal Weather Boot |
| Optional Accessories | Black Grille (GRL-SM500-II-WX-BK)|10" Safety Cable (AC-SM-SC10)|Black Mounting Bracket (AC-SM5-II-WP-BK)|Connector (EUROBLOCK)|Black Weatherboot (WEATHERBOOT-S-BK) |
| Source Inputs | 4 Pin 5.08mm Euroblock |
| IP Rating | IP44 |
| TAA Compliant (Trade America) | No |
| BAA Compliant (Made in USA) | No |
| Crossover Frequency | 3.0 kHz |
| Directivity Factor (Q) (Averaged 100Hz - 10kHz, @ 2kHz) | 5.7 and 9.3 |
| Directivity Index (DI) dB (Averaged 100Hz - 10kHz, @ 2kHz) | 6.0dB and 9.7dB |
| Frequency Response (± 10 dB) | 69 Hz - 22 kHz |
| Frequency Response (± 3 dB) | 100 Hz - 22 kHz |
| Grille Properties | Aluminum, Powder-Coated, Weatherproof |
| Low Frequency Voice Coil | 1 in / 25.4 mm |
| Max. Continuous Power RMS | 80W |
| Max. Program Power | 160 W |
| Minimum Impedance (_ Ohms) | 7 _ |
| Mounting Depth | 10.48 in / 266.2 mm |
| Network Type: High Pass | 12 dB per octave 2nd order |
| Nominal Impedance (_ Ohms) | 8 _ |
| Tweeter Driver | 1" Convex Titanium Horn-Loaded |
| Woofer Driver | 5.25" Polypropylene |
| Sensitivity dB @ 1W/1M | 87 dB |
| Sensitivity dB @ 2.83V/1M | 87 dB |
| Tap Selector | Rotary Switch |
| Transformer Options | 25 / 70.7 / 100 V, 4 Ohm direct |
| Transformer Taps Max. Setting (25V/70.7V/100V) | 8W/64W/64W |
