TOA T-02S Line Input Module for Music-On-Hold - Unbalanced 220K ohm Input
Availability:
In StockAvailable for shipment within one business day, or pickup from our Jamaica, NY warehouse during regular business hours.
Contact us
Description
The T-02S from TOA Electronics is an input module that accepts unbalanced, line-level signals. It also has transformer-isolated output for feeding mixers, amps, recorders, and music-on-hold systems. It has input and output gain adjustment controls and features five screw-terminal connectors. This module is for use with modular devices from TOA Electronics.
| Input Sensitivity | -18 to -2 dBu |
| Gain | |
| Input | -20 to 0dB (Adjustable) |
| Output | 4 to 20dB (Adjustable) |
| Maximum Input/Output | |
| Input | +18dB |
| Output | +18dB |
| Signal to Noise Ratio | |
| Input | 90 dBu |
| Output | 80 dBu |
| Connector | 5 x Screw Terminals |
The T-02S from TOA Electronics is an input module that accepts unbalanced, line-level signals. It also has transformer-isolated output for feeding mixers, amps, recorders, and music-on-hold systems. It has input and output gain adjustment controls and features five screw-terminal connectors. This module is for use with modular devices from TOA Electronics.
| Input Sensitivity | -18 to -2 dBu |
| Gain | |
| Input | -20 to 0dB (Adjustable) |
| Output | 4 to 20dB (Adjustable) |
| Maximum Input/Output | |
| Input | +18dB |
| Output | +18dB |
| Signal to Noise Ratio | |
| Input | 90 dBu |
| Output | 80 dBu |
| Connector | 5 x Screw Terminals |
