TOA U-01P Line Input Module (1/4" Phone Jack)
Availability:
Special Order ItemThis item is not stocked and needs to be ordered from the manufacturer. Please contact our sales team for more information.
Contact us
Description
Line Input Module, Unbalanced, 220k Ohms, Female XLR with Phone Jack
Features- Signal to Noise (S/N): 90 dBu (S/N) Performance Input: 220 k ubControls/Functions: Gain ControlPhysical Connector: U-01F: XLR-F, U-01P: 1/4 phone jack, U-01R: RCA, U-01S: Removable Terminal BlockInput Sensitivity: -18 ~ +12 dBuGain (Adjustable): -30 ~ 0 dBMaximum Input:+18 dB
The U-01P from TOA Electronics is an unbalanced, line-level input module for 900 series products. It is ideal for receiving signals from CD players, AM/FM tuners, and tape decks. The U-01P has a 1/4" (6.3mm) phono jack for device input.
| Input Sensitivity | -18 to +12 dBu |
| Gain | -30 to 0dB |
| Maximum Input | +18dB |
| Signal to Noise Ratio | 90 dBu |
| Connector | 1/4 (6.3mm) Phono Jack |
Line Input Module, Unbalanced, 220k Ohms, Female XLR with Phone Jack
Features- Signal to Noise (S/N): 90 dBu (S/N) Performance Input: 220 k ubControls/Functions: Gain ControlPhysical Connector: U-01F: XLR-F, U-01P: 1/4 phone jack, U-01R: RCA, U-01S: Removable Terminal BlockInput Sensitivity: -18 ~ +12 dBuGain (Adjustable): -30 ~ 0 dBMaximum Input:+18 dB
The U-01P from TOA Electronics is an unbalanced, line-level input module for 900 series products. It is ideal for receiving signals from CD players, AM/FM tuners, and tape decks. The U-01P has a 1/4" (6.3mm) phono jack for device input.
| Input Sensitivity | -18 to +12 dBu |
| Gain | -30 to 0dB |
| Maximum Input | +18dB |
| Signal to Noise Ratio | 90 dBu |
| Connector | 1/4 (6.3mm) Phono Jack |
