TOA U-43R Stereo Input Module with Mute Send - RCA Inputs
Availability:
Special Order ItemThis item is not stocked and needs to be ordered from the manufacturer. Please contact our sales team for more information.
Contact us
Description
For unbalanced, line level equipment such as AM/FM tuners, tape decks and CD players. Signal at input terminals activates mute bus. Choose from two connector types: dual RCA jacks with passive summing or removable terminal block.
The U-43R from TOA Electronics is an input module for 900 series equipment. It accepts unbalanced line-level signals from devices such as CD players, tape decks, and AM/FM tuners. It has dual RCA jacks for device connection. It also has gain control, high and low cut pass filters, and mute send sensitivity.
| Controls/Functions | Gain Control; High and Low Cut Filters; Mute send sensitivity |
| Performance Input | 220 ohms |
| Input Sensitivity | -17 ~ +13 dBu |
| Gain (Adjustable) | -30 ~ -1 dB |
| Signal to Noise (S/N) | 55dBu |
| Physical Connector | Removable Terminal Block |
For unbalanced, line level equipment such as AM/FM tuners, tape decks and CD players. Signal at input terminals activates mute bus. Choose from two connector types: dual RCA jacks with passive summing or removable terminal block.
The U-43R from TOA Electronics is an input module for 900 series equipment. It accepts unbalanced line-level signals from devices such as CD players, tape decks, and AM/FM tuners. It has dual RCA jacks for device connection. It also has gain control, high and low cut pass filters, and mute send sensitivity.
| Controls/Functions | Gain Control; High and Low Cut Filters; Mute send sensitivity |
| Performance Input | 220 ohms |
| Input Sensitivity | -17 ~ +13 dBu |
| Gain (Adjustable) | -30 ~ -1 dB |
| Signal to Noise (S/N) | 55dBu |
| Physical Connector | Removable Terminal Block |
