Waves Axis Scope - Configured SoundGrid Server
Availability:
Special Order ItemThis item is not stocked and needs to be ordered from the manufacturer. Please contact our sales team for more information.
Description
The Waves Axis Scope computer is built from the ground up to deliver maximum stability and performance in Waves SoundGrid systems. Thanks to careful component selection and extensive, rigorous testing, Axis Scope is fully optimized to match the needs of sound engineers using Waves software applications.
Featuring sleek industrial design, elegance, and rugged durability, Axis Scope becomes the “brain” of a complete SoundGrid system that delivers world-class sound reliably—anywhere, anytime.
Features:
- Compact, 2U half-rack size with optional rack ears or shelf
- Custom-built computer, optimized for running Waves applications
- 16 GB DDR4 RAM, 256 GB high-speed internal SSD
- 10th-generation Intel® i5-10600 6-core/12-thread processor
- 6 USB2/USB3 ports, HDMI, display port, external HDMI dongle port
- Pre-loaded with Microsoft Windows 10
- Interfaces seamlessly with SoundGrid I/O devices and servers
- 1 SoundGrid port (EtherCon connector), 1 Ethernet port (RJ45)
| CPU | Intel® i5-10600 |
| RAM | 16 GB |
| Motherboard | Gigabyte GA-IMB410N |
| LAN Card | Intel® I211/I-219 |
| Dimensions | Length: 22 cm / 8.7 in Height: 8.6 cm / 3.4 in Depth: 28.4 cm / 11.2 in |
| Device Weight | 3.4 kg / 7.5 lbs |
| Package Weight | 5 kg / 10.9 lbs |
| Power Consumption | 110/220V 65 W |
| Operating Environment temperature range | 50° to 95°F / 10° to 35°C |
| Max Environment temperature | 104°F / 40°C |
| USB Ports | 2 X Front panel USB 2.0 ports 4 X Back panel USB 3.0 ports |
| Please note | To mount the Axis Scope on a Waves Rack Shelf, only use the 8mm screws provided in the rack shelf package! |
The Waves Axis Scope computer is built from the ground up to deliver maximum stability and performance in Waves SoundGrid systems. Thanks to careful component selection and extensive, rigorous testing, Axis Scope is fully optimized to match the needs of sound engineers using Waves software applications.
Featuring sleek industrial design, elegance, and rugged durability, Axis Scope becomes the “brain” of a complete SoundGrid system that delivers world-class sound reliably—anywhere, anytime.
Features:
- Compact, 2U half-rack size with optional rack ears or shelf
- Custom-built computer, optimized for running Waves applications
- 16 GB DDR4 RAM, 256 GB high-speed internal SSD
- 10th-generation Intel® i5-10600 6-core/12-thread processor
- 6 USB2/USB3 ports, HDMI, display port, external HDMI dongle port
- Pre-loaded with Microsoft Windows 10
- Interfaces seamlessly with SoundGrid I/O devices and servers
- 1 SoundGrid port (EtherCon connector), 1 Ethernet port (RJ45)
| CPU | Intel® i5-10600 |
| RAM | 16 GB |
| Motherboard | Gigabyte GA-IMB410N |
| LAN Card | Intel® I211/I-219 |
| Dimensions | Length: 22 cm / 8.7 in Height: 8.6 cm / 3.4 in Depth: 28.4 cm / 11.2 in |
| Device Weight | 3.4 kg / 7.5 lbs |
| Package Weight | 5 kg / 10.9 lbs |
| Power Consumption | 110/220V 65 W |
| Operating Environment temperature range | 50° to 95°F / 10° to 35°C |
| Max Environment temperature | 104°F / 40°C |
| USB Ports | 2 X Front panel USB 2.0 ports 4 X Back panel USB 3.0 ports |
| Please note | To mount the Axis Scope on a Waves Rack Shelf, only use the 8mm screws provided in the rack shelf package! |
