Description
The DZR315 is 3-way bi-amped powered loudspeaker and is the most powerful model in the DZR Series producing a maximum 143dB SPL with supreme clarity. Best-in-class SPL performance, sophisticated DSP processing, unrivaled low-frequency sound reproduction—the DZR315 delivers on all fronts realizing... Read MoreRetail Price: $2,699.00 Our Price: $1,799.99
Shipping Charges Apply
Suggested Accessories
Description
The DZR315 is 3-way bi-amped powered loudspeaker and is the most powerful model in the DZR Series producing a maximum 143dB SPL with supreme clarity. Best-in-class SPL performance, sophisticated DSP processing, unrivaled low-frequency sound reproduction—the DZR315 delivers on all fronts realizing a truly professional sound delivered with a level of power that belies its compact, lightweight design. Ideal for use in a front of house main PA, it also includes integrated M10 rigging points for suspended applications.
Best-in-class SPL performance, sophisticated DSP processing, unrivaled low-frequency bass sound reproduction— the new DZR delivers on all fronts realizing a truly professional sound delivered with a level of power that belies its compact, lightweight design.
Features:
More +
Product Specs
Speaker type | 3-way, Bi-ampled Powered Speaker, Bass-reflex | |
---|---|---|
Frequency range (-10dB) | 31Hz - 20kHz | |
Coverage area | H75゚ x V50゚ | |
Components | LF | 15" Cone, 3" Voice Coil, Neodymium magnet |
MF | 8" Cone, 1.5" Voice Coil, Ferrite magnet | |
HF | 2" Voice Coil, 1" Throat Compression Driver, Titanium diaphragm, Neodymium magnet | |
Crossover | 700Hz (FIR-X), 2.5kHz (Passive) | |
Sampling frequency rate | Internal | 96kHz and FIR Filter |
A/D D/A Converters | 96kHz AD/DA | |
Maximum output level (1m; on axis) | 143dB SPL *1 | |
Power rating | Dynamic | 2000W (LF:1000W, MF/HF: 1000W) *2 |
Continuous | 1300W (LF: 920W, MF/HF: 380W) | |
I/O Connectors | Analog I/O | Analog IN: Combo x2, Line level (Maximum +24dBu), Input impedance 20kΩ, Analog OUT: XLR3-32 x2, CH1: THRU (fix), CH2: THRU or DSP OUT |
Others | USB2.0 Host 5V 500mA for USB memory DATA storage/load | |
AC | IEC AC inlet x1 (V-Lock) | |
Amplifier class | Class-D | |
Cooling | Fan cooling, Variable speeds | |
Power consumption | 45W (Idle), 150W (1/8) | |
Handle | Aluminium die-cast, Side x2 | |
Rigging | M10 x16 | |
Dimensions | W | 550 mm (21.6") |
H | 897 mm (35.3") (with rubber feet) | |
D | 520 mm (20.5") | |
Net weight | 41.6kg (91.7lbs) | |
Options | Cover: SPCVR-DZR315 | |
Others | Enclosure Material, Finish, Color: Plywood, Durable Polyurea Painting, Black | |
Floor Monitor Angle | - | |
Pole socket | - |
