Yamaha MGP24X 24 Input 4 Bus Hybrid Analog/Digital Console



Have a Question? Call Toll Free: 888-462-7828

Live Chat Email Us
Dale #:YAMA-MGP24X

Availability: Usually ships in 5 - 10 Days

This item usually ships within 5-10 days after your order is placed. Your payment will be charged after completing checkout.
Free Shipping (Continental US)
  • From the preamps, EQ and effects to the Hybrid Channel functions and iPod/iPhone connectivity—every aspect, every feature, every sound, establishes the MGP as a premium mixing console in a class of its own. Drawing from decades of experience crafting innovative, premium analog gear, Yamaha originally developed their new discrete Class-A microphone preamps for professional use in their high-end recording equipment. Utilizing an inverted Darlington circuit design, these newly-refined D-PRE mic preamps deliver a fat, rich, smooth tone that gives the MGP Series a significant advantage over any other mixer in its class.

    With Yamaha's proprietary X-pressive EQ Yamaha managed to capture ultimate analog authenticity by unlocking the mysterious secret behind the expressive sound shaping capabilities of sought-after classic EQ modules. At the heart of the MGP's compact configuration, they've taken an innovative new approach to the utilization of digital technology in an analog mixer; adding high-resolution effects, iPod/iPhone integration and the superb functionality of the new Stereo Hybrid Channel to the warmth and musicality of premium analog sound. The MGP Series represents the ultimate balance of the converging technologies that are the heart and soul of Yamaha's extraordinary achievements in professional audio.

    Features:

    • 16 Mic Inputs with 48V Phantom Power and HPF per Channel
    • 24 Line Inputs (16 mono and 4 stereo)
    • 6 AUX Sends + 2 FX Sends
    • 4 GROUP Buses + ST Bus
    • 2 Matrix out
    • 1 Mono out
  • Mixing capability Mixing channels 24 Line Inputs (16 mono and 4 stereo)
    GROUP 4 GROUP Buses + ST Bus
    AUX 6 AUX Sends + 2 FX Sends
    MATRIX 1 Matrix out
    On-board processors FX1:REV-X(8 PROGRAM, PARAMETER control)/ FX2:SPX(16 PROGRAM, PARAMETER control)
    I/O Mic inputs MIC: 16 (INPUTS HPF: 100Hz 12dB/oct)
    Phantom power 48V phantom power per channel
    Line inputs LINE: 16 mono + 4 stereo, CH INSERT: 16 RETURN: 1 stereo
    Digital I/O USB Device, iPod / iPhone
    Total harmonic distortion 0.02% (20Hz-20kHz@ +14dBu)
    Frequency response +0.5/-1.0dB 20Hz - 20kHz, refer to the nominal output level @1kHz
    Hum & noise level Equivalent input noise -128 dBu Equivalent Input Noise
    Residual output noise -94 dBu Residual Output Noise
    Crosstalk -74dB @ 1kHz
    Power requirements 100-240V 50Hz/60Hz
    Power consumption 86W max
    Dimensions W 819mm (32.2)
    H 169mm (6.7)
    D 565mm (22.2)
    Net weight 15.5kg (34.2lb)
