Description
Lo-Z/Hi-Z switchable Class-D amplifier (Lo-Z: 120W x2 @4?, 100W x2ch @3?/8?, Hi-Z: 120W x2ch or 200W x1ch, 70V/100V) equipped with 1 stereo/2 mono line inputs; can be combined with the MA2120 mixer amplifier. With quick, easy setup and intuitive operation, the compact MA and PA series power ampli... Read MoreRetail Price: $817.00 Our Price: $693.99
Free Shipping (Continental US)
Suggested Accessories
Description
Lo-Z/Hi-Z switchable Class-D amplifier (Lo-Z: 120W x2 @4?, 100W x2ch @3?/8?, Hi-Z: 120W x2ch or 200W x1ch, 70V/100V) equipped with 1 stereo/2 mono line inputs; can be combined with the MA2120 mixer amplifier.
With quick, easy setup and intuitive operation, the compact MA and PA series power amplifiers make it easier than ever to bring your commercial space to life. The MA2030a and PA2030a are ideal audio solutions for retail stores, eateries, classrooms or public facilities like hospitals. The MA2120 and PA2120 meet the demands of a wide range of applications requiring higher power as well as more flexible DSP functionality and zone control. All models combine approachable, unobtrusive design with efficient, flexible performance. The MA2030a and MA2120 offer mixing capability with source EQ (Bass/Treble) control, as well as some of the same state-of-the-art DSP technol-ogies that are acclaimed features of professional Yamaha audio gear. Whether providing background music for a café or restaurant or powering a conference room or other application requiring microphone input, the MA/PA series amplifiers are simple yet powerful tools that can help establish an ideal commercial sound environment. - Simple, user-friendly interface - Stereo and microphone inputs (MA series) - DSP functions optimized for background music (MA series) - Switchable for low (3/4/8 ?) and high (70/100 V) impedance speaker systems - Stereo source EQ with enhancer function (MA series) - EQ for optimum performance with Yamaha VXC/VXS series speakers built in - Easy service zone expansion with PA series amplifiers (PA2030a excluded) - Optional DCP control panels allow convenient remote volume control, microphone ON/OFF switching and chime activation (PA2030a excluded) - Industry leading Yamaha quality control and reliability - Compact, space-saving design* * All models are naturally cooled designs that require sufficient surrounding space for airflow.
Features:
More +
Product Specs
Output power | 1kHz (THD+N=1%: 3Ω) | 100W x 2 (20ms Burst) |
1kHz (THD+N=1%: 4Ω) | 120W x 2 (20ms Burst) | |
1kHz (THD+N=1%: 8Ω) | 100W x 2 (20ms Burst) | |
High impedance: 100V line | 120W x 2 or 200W x 1 | |
High impedance: 70V line | 120W x 2 or 200W x 1 | |
Total harmonic distortion | ≤0.2% (Line in to Speaker out, Half power @1kHz, 3Ω/4Ω/8Ω), ≤0.2% (Line in to Speaker out, Half Power @1kHz, 70V/100V, 120W/200W) | |
Frequency response | 0dB, -2.5dB, +1.0dB (Line in to THRU OUT, 20Hz to 20kHz), 0dB, -3.0dB, +1.0dB (Line in to Speaker out, 50Hz to 20kHz, 1W, 3Ω/4Ω/8Ω), 0dB, -3.0dB, +1.0dB (Line in to Speaker out, 90Hz to 20kHz, 1W, 70V/100V, 120W/200W) | |
Crosstalk | - | |
I/O Connectors | Mic/Line Input | - |
Line Input | Input A-B:MONO RCA pin x 2 (unbalanced) or 3.5mm Euro block (6-pin, balanced) | |
Speaker Output | Barrier strip x 2 pairs | |
Line Out | THRU OUT: MONO RCA pin (unbalanced) x2 | |
Control ports | RJ-45 (for DCP4V4S, DCP1V4S , DCP4S), Remote (3.5mm Euro block 3-pin) | |
Mic Input | - | |
Stereo Input | - | |
Input Level | Line input (unbalanced): -10dBV (Sensitivity), -10dBV (Nominal), +10dBV (Max before clip) / Line input (balanced): +4dBu (Sensitivity), +4dBu (Nominal), +24dBu (Max before clip) | |
Output Level | -10dBV (THRU OUT, Nominal) | |
Processors | Speaker EQ (VXS:Full Range, VXC, VXS10S/ST), HPF (150Hz), LPF (150Hz, 200Hz) | |
Protection circuit | Load protection | Power switch on/off: Mute the output*, Output voltage protection: Compress the output*, DC-fault: Power supply shutdown (*Restored automatically) |
Amplifier protection | Thermal: Limit the output* → Mute* → Shutdown, Over current: Mute the output*, Integrated power limit: Compress the output* (*Restored automatically) | |
Power supply protection | Thermal: Power supply shutdown, Over voltage: Power supply shutdown, Over current: Limit the output* →Power supply shutdown (*Restored automatically) | |
Amplifier class | Class D | |
Cooling | Conventional cooling, bottom to up airflow | |
Power requirements | 100V, 120V, 230V - 240V, 50Hz / 60Hz | |
Power consumption | 60W (1/8 max power, 4Ω, AC100V, pink noise at all channels) | |
Dimensions | W | 480mm (18.9”) *1 |
H | 45mm (1.8”) *1 | |
D | 379mm (14.9”) *1 | |
Net weight | 4.8kg (10.6lbs) | |
Accessories | AC power cable, 3.5mm Euroblock plug (6-pin) x 1, Euroblock pulg (3-pin) x 1, Owner's manual, Specification sheet | |
Options | DCP4V4S, DCP1V4S, DCP4S (Digital Control Panel) | |
Certificate | ENERGY STAR | |
Others | Operating Temperature: 0°C to + 40°C, Storage Temperature: -20°C to + 60°C, Rack-mountable when ensuring sufficient ventilation above and below the unit |
