Anchor Audio AN-MINI-U2BT - Personal PA System with Bluetooth and Wireless Microphone Receivers
Availability:
Special Order ItemThis item is not stocked and needs to be ordered from the manufacturer. Please contact our sales team for more information.
Description
The AN-MINI/MiniVox ¨ is a powerful personal portable PA system. It is wearable, compact, and lightweight, so you can take it anywhere Ð perfect for on the go, tours, field trips, emergency preparedness, mission trips, and more!
Connect up to two wireless microphones.
| Weight | 2.6 lbs |
| Dimensions: (Height x Width x Depth) | 7" x 6" x 3.5" |
| Coverage | * area: approximately 20' x 30' * crowd size: approximately 100 |
| Drivers | One 4.5" Neodymium Woofer |
| Rated Power Output | 30 watts |
| Max SPL @ Rated Power | 100 dB @ 1 meter |
| Frequency Response | 100 Hz ~ 15 kHz ± 3dB |
| AC Power Reqs | 100~240 VAC, 50/60 Hz, 2A |
| Charger/Power Inlet | PC-2 |
| Battery | 10 AA Alkaline, or 10 Rechargeable Lithium Iron Phosphate (LiFePo4) |
| AnchorLink Wireless Frequency | 1920~1930 MHz USA/CAN 1880~1900 MHz Europe |
| AnchorLink Wireless Range | 300'+ line of sight |
| AnchorFlex Frequency Range | 902~928 MHz USA/CAN 606~614MHz Europe |
| Microphone Inputs | * Lo-Z, balanced, XLR / 1/4" * 34 V DC condenser mic (phantom) power * Hi-Z (10 k_), unbalanced, 1/4" phone |
| Line Input | One 3.5 mm line level |
| Line Output | One 3.5 mm line level |
The AN-MINI/MiniVox ¨ is a powerful personal portable PA system. It is wearable, compact, and lightweight, so you can take it anywhere Ð perfect for on the go, tours, field trips, emergency preparedness, mission trips, and more!
Connect up to two wireless microphones.
| Weight | 2.6 lbs |
| Dimensions: (Height x Width x Depth) | 7" x 6" x 3.5" |
| Coverage | * area: approximately 20' x 30' * crowd size: approximately 100 |
| Drivers | One 4.5" Neodymium Woofer |
| Rated Power Output | 30 watts |
| Max SPL @ Rated Power | 100 dB @ 1 meter |
| Frequency Response | 100 Hz ~ 15 kHz ± 3dB |
| AC Power Reqs | 100~240 VAC, 50/60 Hz, 2A |
| Charger/Power Inlet | PC-2 |
| Battery | 10 AA Alkaline, or 10 Rechargeable Lithium Iron Phosphate (LiFePo4) |
| AnchorLink Wireless Frequency | 1920~1930 MHz USA/CAN 1880~1900 MHz Europe |
| AnchorLink Wireless Range | 300'+ line of sight |
| AnchorFlex Frequency Range | 902~928 MHz USA/CAN 606~614MHz Europe |
| Microphone Inputs | * Lo-Z, balanced, XLR / 1/4" * 34 V DC condenser mic (phantom) power * Hi-Z (10 k_), unbalanced, 1/4" phone |
| Line Input | One 3.5 mm line level |
| Line Output | One 3.5 mm line level |
